Page 1 7402‐K598 Pedestal Sign Holder Kit Instructions Issue A...
Page 2 Revision Record Issue Date Remarks Apr 2009 First issue...
Page 3 Introduction This kit provides a channel to hold an information sign on the either side of the 2336-K052 or 7409-K055 floor pedestals. Note: Two channels (two kits) can be used to support a full wrap-around sign. Thumbscrew, 8-32 x 7/16, Knurled w/Shoulder 006-8612853 Screw, #8 x 3/4",...
Page 4 Installation Procedures (2336-K052 Pedestal) 1. Install the grommets (5) into the square holes on the side of the pedestal. 2. Secure the Sign Channel to the pedestal with screws (5). 3. Insert the sign into the bracket and secure it with the thumbscrews. 27613 Full Wrap-Around Sign Two channels can be used if it is desirable to install a sign that wraps around the pedestal.
Page 5 Dimensions Use the dimensions below to create the full wrap-around sign. The sign can have a maximum thickness of 11 mm (0.45 in.). The thumbscrews that secure the sign are spaced 305 mm (12 in.) apart. 210 mm 13 mm (8.25 in.) (0.5 in.) 9.7 mm...
Page 6 Installation Procedures (7409-K055 Pedestal) 1. Install the grommets (5) into the square holes on the side of the pedestal. 2. Secure the Sign Channel to the pedestal with screws (5). 3. Insert the sign into the bracket and secure it with the thumbscrews. 27619 Full Wrap-Around Sign Two channels can be used if it is desirable to install a sign that wraps around the pedestal.
Page 7 Dimensions Use the dimensions below to create the full wrap-around sign. The sign can have a maximum thickness of 11 mm (0.45 in.). The thumbscrews that secure the sign are spaced 305 mm (12 in.) apart. 13 mm 363 mm (0.5 in.) (14.3 in.) 9.7 mm...
