Specifications - Chasing M2 User Manual

Navigation
M2 has 8 Vectored Thrusters layout which allows OMNI movement (up, down, left and right, back and forth,
pitch, roll, and pan) in all directions. The default is basic control mode, suitable for beginners. Navigation
attitude and remote control are as follows:
Remote Rov
Controller
(Flight Direction)
Forward/backward
Left Joystick
Right Rocker Pan Left and Right
Scroll the Turn the Dial To Adjust
Left Wheel the Pitch Attitude
If necessary, users can switch modes by long pressing the "One-key reset " button of the remote controller.
When switching to the advanced mode, the ROV can achieve all-round full-freedom movement.
The advanced mode is based on the first-person perspective.
Charging Guidance
ROV & Remote Controller
Adapter （ 25.2V 2.9A) : It is a 3 in 1 charger that could charge the ROV, Remote Controller, Battery Cabin & E-reel，
Red light indicates Charging, green light indicates fully charged.
* Note: in the basic mode, the maximum Angle of pitch and roll is about 80 degrees.
Remote Rov
Controller
(Flight Direction)
Turn Left / Right
Left Joystick
Right Rocker Up / Down
Scroll the Turn the Dial to Adjust The Roll
Right Wheel Attitude, Release to Fix Status
Specifications
ROV
Size 15*10.5*6.5 inch
Weight 4.5kg
Battery 97.68Wh
Maximum Depth 328 ft
Maximum Speed 1.5 m/s (3 Knots)）
≤4h
Battery Life
(Depend on working condition)
Battery Cycle >300times
Operating
14℉~113℉
Temperature
Camera
CMOS 1/2.3
Aperture F1.8
Focal Length 1m
ISO Range 100-6400
Field of View 152°
Maximum Image
12M
Resolution
Image File Types JPEG/DNG
4K UHD:3840*2160 30fps
Normal video
FHD:1920*1080 30/60/120fps
720P： 8x (240fps)
Slow motion video
1080P： 4x (120fps)
Time-lapse video 4K/1080P
Video Maximum
60M
Stream
Video Type MP4
Standard 64G
SD Card Memory
(maximum support 512G)
Dimmable LED Lights
Brightness 2 x 2000lm
Color Temperature 5000K~5500K
CRI 85
Dimming Three adjustable
Remote Controller
Size 6.3*6.1*4.9 inch
Weight 0.685kg
Battery capacity 2500mAh
≥6H (Depend on working
Battery life
condition)
Wireless Wi-Fi
HDMI 1080P
Tether & Winder
328ft Version (100M) 1.8kg
656ft Version(200M) 2.5kg
Adapter
Adapter 2.9A/25.2V
ROV Charging time 2.5h
Remote controller
2h
charging time
Sensor
Three-axis gyroscope
IMU acceleration
compass
Depth Sensor ＜±0.25m
Temperature Sensor ＜±2℃
