Sport-thieme 126 4920 Operating & Assembly Instructions

Operating/assembly instructions
Exercise mat storage trolley
Prod. code: 126 4920
Thank you very much for choosing a Sport-Thieme product. Please read the
instructions fully before you assemble the equipment so you can enjoy the product
and its guaranteed safety.
When you open the package, please ensure all the necessary parts are included:
(1) 1 x base with mounted swivel castors
(2) 2 x aluminium rails with 4 T-nuts, 4 washers 8.5 x 34 x 1.5 and 4 bars ø 14
with thread M8 (pre-assembled)
(3) 2 x post 30 x 30
(4) 4 x star knob screw M8 x 40
(5) 4 x washer 8.4 x 20 x 2.0
(6) 4 x socket head screw with nut M10 x 60
(7) 4 x wedge plate M8
Operating/assembly instructions
for exercise mat storage trolley
Illustration 1: mat transport trolley
