- Page 1 Commissioning and Maintenance Instructions TAM00721_ DSD-028/DSD-036 DSD2-028/DSD2-036 Three-phase-synchronous motor TAM00721 Version: 04/2013 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English English...
- Page 2 No liability can be accepted concerning the correctness of this documentation unless otherwise specified in the General Conditions of Sale and Delivery. BAUMÜLLER DirectMotion GmbH D-37581 Bad Gandersheim www.baumueller.de TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English...
-
Page 3: Table Of Contents
7.6 ECN1325 / EQN 1337 (encoder with EnDat 2.2-port from Heidenhain companies; M12, 8-polig) ..........................23 7.7 ECN1325 / EQN 1337 (encoder with EnDat 2.2-port from Heidenhain companies; M23, 9-polig) ..........................23 TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 4: General Safety Instructions
Failure to observe can lead to serious injury Warning about a hot surface Electrostatically sensitive components Failure to observe can lead to damage to the system or peripheral equipment. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 5: Designated Purpose
If, in special cases (for utilization in non-industrial applications), more stringent requirements are in place, e. g., protection against contact with a child's fingers, these conditions must be met by the customer when installing the system. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 6: Prohibition Of Unauthorized Modifications And Changes
Baumüller head office in Nuremberg should be notified immediately. In both of the above cases, commissioning must not take place until the error has been rectified by a specialist. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 7: Nameplate
20 Rated power P 9 Article number ID 10 Motor is run with a converter 21 Rated voltage U 11 Rated frequency f 22 Motor type: 3 phase motor TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 8: Technical Data
If the electric motor supplied is not a standard type as per the technical documentation or if special contractual arrangements have been made, there may technical differences to these Commissioning and Maintenance Instructions. In this case request the related technical supplements. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 9: Transport, Bearing Lock, Intermediate Storage
Aggressive, corrosive, abrasive and plastic-dissolving solutions should be kept well away from the motor and the air that is used to cool it. Consultation with the motor manufacturer is essential in the case of installation outdoors. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 10: Balancing, Output Elements, Vibration
When pulling, use intermediate washers to provide the shaft with mechanical protection. • When hoisting heat up the drive elements if required (max. permissible temperature at shaft end 150°C). TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... - Page 11 Where there are deviations from normal operation – e. g., rise in temperature, noises, vibration – switch off the motor. Identify the cause and, if necessary, contact the manufacturer. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English...
-
Page 12: Mounting
On motors with a brake fitted, release the brake beforehand. • the design of the motor and encoder cables complies with the details in the technical documentation that accompanies the product. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 13: Electrical Connections
5 times altogether. • Connectors must not be exposed to mechanical stress. If necessary, protect against strain, shearing, twisting and kinking. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 14: Commissioning, Operation
The cables are not in contact with the surface of the motor. • The drive is not blocked (release brake, if present). • Emergency stop functions have been checked TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 15: Commissioning, Operation
• Refer to the operating instructions for the machine/system. • Refer to the operating instructions for the converter. • If necessary, contact the manufacturer of the motor or converter. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... - Page 16 Brake not releasing fully – brake Have repaired by motor manufacturer dragging Current consumption too Indexing angle incorrect Check indexing angle and adjust if high, motor torque too low necessary Table 3: Malfunctions TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English...
-
Page 17: Inspection And Maintenance
The motor must be disposed of in accordance with the relevant national and local regulations within the framework of the normal recycling process. The encoder electronics (if provided) must be disposed of in the proper manner as electronic scrap. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 18: Pole Assignment (Main Connection And Control Port)
10 P REF + REF - Housing s.c. Figure 2: Resolver-KTY on power connection s.c.: shield connection (1) brake optional; see nameplate Schematic: view of the contact side TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 19: Resolver - Kty On Signal Connection
KTY - Temp.- Sensor KTY + Housing s.c. Figure 3: Resolver-KTY on signal connection s.c.: shield connection (1) brake optional; see nameplate Schematic: view of the contact side TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 20: Srs/Srm50; Sks/Skm36; Sek/Sel37 - Kty On Power Connection
Daten - + COS 10 P Housing s.c. Figure 4: Hiperface-port-KTY on power connection s.c.: shield connection (1) brake optional; see nameplate Schematic: view of the contact side TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 21: Srs/Srm50; Sks/Skm36; Sek/Sel37 - Kty On Signal Connection
Temp.- KTY + Sensor KTY - Housing s.c. Figure 5: Hiperface-port-KTY on signal connection s.c.: shield connection (1) brake optional; see nameplate Schematic: view of the contact side TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 22: Ecn1313 / Eqn 1325 (Encoder With Endat 2.1-Port From Heidenhain Companies; M23, 17-Polig)
(encoder with EnDat 2.1-port from Heidenhain companies; M23, 17-polig) Signal Clock Ansicht auf Kontaktseite der Gerätedose Clock inv. Data Data inv. Figure 6: pole assignment ECN 1313 / EQN 1325 TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... -
Page 23: Ecn1325 / Eqn 1337 (Encoder With Endat 2.2-Port From Heidenhain Companies; M12, 8-Polig)
• For other encoder types and optional lead for the temperature sensor via the encoder cable, see the enclosed wiring diagram or technical documentation for the pin assignment • The encoder from Section 7.3 to 7.7 are components susceptible to ESD. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor English... - Page 24 The latest version of the General Terms and Conditions of Sale of Baumüller Nürnberg GmbH always apply. These will be made available to you at the latest on conclusion of the contract. TAM00721 DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013 Three-phase-synchronous motor...
