Batteries
2.5.1.4

CPU Battery Low Indication

The rechargeable battery will not reliably provide the CPU with a battery low indication. User logic should not rely
on any of the battery status bits when using this battery.
2.5.1.5

Diagnostics

This unit is not user-serviceable. The IC690RBT001 contains a self-resetting thermal protection device that
disconnects the battery if the cell temperature exceeds 90ºC.
2.5.2

IC690CRG001

The IC690CGR001 Battery Charger is intended for use only with the IC690RBT001 rechargeable battery.
2.5.2.1

Specifications

Parameter
Input Power
Maximum output power
Physical dimensions
Weight
Operating Temperature range
2.5.2.2

Operation

Charging begins when a battery pack is connected to the charger. The LED is initially orange, and changes to red
when the fast charge starts. When the cells are fully charged, the charger goes into top-off charge mode before
switching to trickle charge mode. During the top-off charge, the LED is green with short, intermittent orange
flashes. When the top-off charge is complete, the charger goes into trickle charge mode, and the LED color
changes to green.
If the charger detects a fault, the charger will stop the fast charge current and switch to trickle charge mode. The
LED will then indicate error by flickering green and red. The fault condition can be caused by the battery pack,
wiring, or the charger.
If input power is turned off, the charger will reset. The charger starts a new charge cycle when the power is turned
back on.
2.5.2.3

Indicators

10
100–240Vac, 50–60Hz, 0.35A maximum
8W
3.55" long x 1.77" wide x 1.26" high (90 x 45 x 32 mm)
115 grams
0 to +60ºC
LED
Orange No battery / Initialization
Red Fast charge
Green/Orange Top-off charge
Green Trickle charge (fully charged)
Red/Green Error
PACSystems* Controllers Battery and Energy Pack Manual
Specification
Mode
GFK-2741D
