Rechargeable Batteries
2.5
2.5.1
IC690RBT001
The IC690RBT001 Rechargeable Battery provides an extended backup time for volatile memory on PACSystems
CPUs compared to that of the standard memory backup battery (IC698ACC701).
2.5.1.1
Specifications
Parameter
Battery capacity
Battery construction
Lithium content
Physical dimensions
Case material
Connection
Operating temperature range
Nominal shelf life
Operating life @ 50ºC
Compatible Charger
2.5.1.2
Nominal Battery Life
The nominal battery life at 50ºC is 12 months or 60 charge/discharge cycles. Battery life is negatively affected by
higher temperatures, and can be significantly improved by operating closer to room temperature (25ºC). When
deciding where to mount the battery, consider how the mounting location will affect the battery temperature. For
most industrial installations, mounting the battery below the PLC rack will result in a temperature closer to 25ºC
and will help improve battery life. Do not operate the battery at less than 0ºC or greater than 50ºC.
The battery will continue to operate after 12 months or 60 charge/discharge cycles, however the battery capacity
will decline and the times listed in the Battery Compatibility and Memory Retention Time in Days at 20°C chart will no
longer be valid.
2.5.1.3
Battery Mounting
With power removed from the equipment, drill four #29 (0.136") (3.45mm) holes in the panel mounting surface, and
tap for #8-32 threads, according to the hole pattern shown in the following figure. Use care to keep metal chips
from falling into other equipment. Securely attach the rechargeable battery module to the panel mounting surface
using four #8-32 x ½" (M4x0.7x12mm) flat head machine screws.
#8-32 (four places)
2.250" (57.15 mm)
GFK-2741D
7.0 Amp-hours
3-cell, nickel-metal hydride
None
6.902" long x 3.150" wide x 1.819" high (175.3 x 80.0 x 46.2 mm)
Black, flame-retardant ABS plastic
2' (60cm) twisted red/black 22 AWG (0.326mm
compatible with the battery connector on PACSystems CPUs.
0 to +50ºC
3 years@ 20ºC
12 months or 60 charge-discharge cycles
IC690CRG001
163.45 mm)
(
June 2015
Specification
2
) cable with female two-pin connector
6.435"
Batteries
9
