WebDAQ LEDs behave differently when so ware is updated on the device. The following table defines the LED
states during a so ware update.
LED
All LEDs
POWER
STATUS
ERROR
Refer to Upda ng WebDAQ firmware
SD card slot
The SD slot accepts SD (Secure Digital), SDHC, SDXC, MMC, and TransFlash memory cards. Memory cards can be
ejected using the web interface or the hardware FUNC bu on, unless the bu on is configured to start/stop an
acquisi on.
When removable media is plugged into the WebDAQ, the opera ng system opens it for wri ng. Use the FUNC
bu on or web interface to unmount the SD card before removing.
Factory reset bu on
The recessed bu on labeled CONFIG RESET restores factory default se ngs. When pressed, the default se ngs
are wri en to the device and the WebDAQ is rebooted. Refer to the
a list of the default se ngs that are restored.

Ethernet connector

The WebDAQ has one 10 Base-T/100 Base-TX, auto-nego a on, high-speed communica on port. The port
connector is an RJ-45, eight-posi on connector. The Ethernet port accepts shielded or unshielded twisted pair
cable. The maximum communica on distance without using a repeater is 100 m (328 ). For CE compliance the
maximum distance is 3 m (9.84 ).
Ground connector
The WebDAQ ships with a ground screw in the connector labeled #6-32. To ground the WebDAQ chassis, a ach
a ring lug to a 14 AWG (1.6 mm) wire. Connect the ring lug to the grounding screw on the WebDAQ rear panel.
A ach the other end to a safety ground.
LED states – so ware update mode
State
Solid yellow
Blinking yellow
Blinking green
Blinking yellow
Blinking green
Blinking yellow
for more informa on about WebDAQ firmware.
WebDAQ 316 User's Guide
Descrip on
So ware update is star ng
So ware update is running
Update file is located; device is being updated
Update file cannot be located; insert media with update
file
Update is successful; device will reboot in approximately
5 seconds
Update failed; user must retry
Restore factory default se ngs
page 15
sec on for
