Spring terminal

Table 20. Spring terminal pinout
# Label
1 NC
2 TC0[+]
3 TC1[+]
4 TC2[+]
5 TC3[+]
6 TC4[+]
7 TC5[+]
8 TC6[+]
9 TC7[+]
10 TC8[+]
11 TC9[+]
12 TC10[+]
13 TC11[+]
14 TC12[+]
15 TC13[+]
16 TC14[+]
17 TC15[+]
18 COM
Contents
Terminal
Use
No connec on
Channel 0 HI
Channel 1 HI
Channel 2 HI
Channel 3 HI
Channel 4 HI
Channel 5 HI
Channel 6 HI
Channel 7 HI
Channel 8 HI
Channel 9 HI
Channel 10 HI
Channel 11 HI
Channel 12 HI
Channel 13 HI
Channel 14 HI
Channel 15 HI
Common
WebDAQ 316 User's Guide
# Label
29 NC
30 TC0[–]
31 TC1[–]
32 TC2[–]
33 TC3[–]
34 TC4[–]
35 TC5[–]
36 TC6[–]
37 TC7[–]
38 TC8[–]
39 TC9[–]
40 TC10[–]
41 TC11[–]
42 TC12[–]
43 TC13[–]
44 TC14[–]
45 TC15[–]
46 COM
page 30
Terminal
Use
No connec on
Channel 0 LO
Channel 1 LO
Channel 2 LO
Channel 3 LO
Channel 4 LO
Channel 5 LO
Channel 6 LO
Channel 7 LO
Channel 8 LO
Channel 9 LO
Channel 10 LO
Channel 11 LO
Channel 12 LO
Channel 13 LO
Channel 14 LO
Channel 15 LO
Common
