WebDAQ LEDs behave differently when so ware is updated on the device. The following table defines the LED
states during a so ware update.
LED State
All LEDs Solid yellow
POWER Blinking
yellow
STATUS Blinking
green
Blinking
yellow
ERROR Blinking
green
Blinking
yellow
Refer to Upda ng WebDAQ firmware

SD card slot

The SD slot accepts SD (Secure Digital), SDHC, SDXC, MMC, and TransFlash memory cards. Memory cards can be
ejected using the web interface or the hardware FUNC bu on, unless the bu on is configured to start/stop an
acquisi on.
When removable media is plugged into the WebDAQ, the opera ng system opens it for wri ng. Use the FUNC
bu on or web interface to unmount the SD card before removing.
Acquiring data at high speeds can generate large file sizes
If you expect to acquire a large amount of data to a single file when logging to external media, do not
use media forma ed with the FAT32 file system. FAT32 is limited to a 4 GB maximum file size. If the log
file on FAT32 media grows beyond that size, a "File too large" error is returned and the acquisi on stops.
Before star ng a logging session of this type, reformat the media using a different file system such as
NTFS. Refer to the Frequently Asked Ques ons help topic for more informa on about file systems.

Factory reset bu on

The recessed bu on labeled CONFIG RESET restores factory default se ngs. When pressed, the default se ngs
are wri en to the device and the WebDAQ is rebooted. Refer to the
a list of the default se ngs that are restored.

Ethernet connector

The WebDAQ has one 10 Base-T/100 Base-TX, auto-nego a on, high-speed communica on port. The port
connector is an RJ-45, eight-posi on connector. The Ethernet port accepts shielded or unshielded twisted pair
cable. The maximum communica on distance without using a repeater is 100 m (328 ).

Ground connector

The WebDAQ ships with a ground screw in the connector labeled #6-32. To ground the WebDAQ chassis, a ach
a ring lug to a 14 AWG (1.6 mm) wire. Connect the ring lug to the grounding screw on the WebDAQ rear panel.
A ach the other end to a safety ground.
WebDAQ 504 User's Guide
LED states – so ware update mode
Descrip on
So ware update is star ng
So ware update is running
Update file is located; device is being updated
Update file cannot be located; insert media with update file
Update is successful; device will reboot in approximately 5 seconds
Update failed; user must retry
for more informa on about WebDAQ firmware.
page 13
Restore factory default se ngs sec on for
