Safety voltages

Connect only voltages that are within the limits specified in this table.
Table 17. Safety specifica ons
Parameter
Between any two
terminals
Channel-to-
channel isola on
Channel-to-earth
ground isola on
Note 9. Measurement Category II is for measurements performed on circuits directly connected to the
electrical distribu on system. This category refers to local-level electrical distribu on, such as that provided by
a standard wall outlet, for example 115 V for US or 230 V for Europe.
Cau on! Do not connect the device to signals or use for measurements within Measurement Categories
III or IV.

Signal connectors

Table 18. Screw terminal specifica ons
Parameter
Connector types

Screw terminal

wiring
Spring terminal
wiring
Screw terminal
Table 19. Screw terminal pinout
# Label
1 GND
2 DIO0
3 DIO1
Condi ons Specifica on
±30 V max
None
Con nuous 250 Vrms, Measurement Category II
Withstand 2300 Vrms, verified by a 5 second dielectric withstand test
Specifica on
36-posi on spring terminal for thermocouple connec ons
6-posi on screw terminal for digital connec ons
14 to 30 AWG copper conductor wire with 5 to 6 mm (0.20 to 0.24 in.) of insula on
stripped from the end
16 to 28 AWG copper conductor wire with 7 mm (0.28 in.) of insula on stripped from
the end
Terminal
Use
Digital ground
Digital bit 0
Digital bit 1
WebDAQ 316 User's Guide
# Label
4 DIO2
5 DIO3
6 GND
page 29
(Note 9)
Terminal
Use
Digital bit 2
Digital bit 3
Digital ground
