If an extension cord is
WARNING
!
necessary, a cord with
adequate size conductors that is capable
of carrying the current necessary for your
tool must be used. This will prevent
excessive voltage drop, loss of power or
overheating. Grounded tools must use 3-
wire extension cords that have 3-prong
plugs and receptacles
.
NOTE: The smaller the gauge number, the
heavier the cord.
* Standard parallel width guide fence
** Deluxe angle fence
** Rabbeting depth stop
* Blade wrench 2.5mm
* Carbide reversible blades (2)
* Vacuum connector
8:47 AM Page 13
Accessories
RECOMMENDED SIZES OF EXTENSION CORDS
120 VOLT ALTERNATING CURRENT TOOLS
Cord Size in A.W.G.
Tool's
Ampere
Cord Length in Feet
Rating
25 50
3-6
18 16
6-8 18 16
8-10 18 16
10-12 16 16
12-16
14 12
** Vacuum hose
** Chip bag
(*= standard equipment)
(**= optional accessories)
-13-
2
Wire Sizes in mm
Cord Length in Meters
100 150 15 30 60 120
16 14 0.75 0.75 1.5 2.5
14 12 0.75 1.0 2.5 4.0
14 12 0.75 1.0 2.5 4.0
14 12 1.0 2.5 4.0 —
— — — — — —
