Thank you for choosing the Yard Master WraithVeil® Dual portable projection screen! Please read through this user
guide before utilizing the screen. Correct usage and maintenance will ensure a long product life.
Care & Use Instructions
◆
Elite Screens highly recommends two people to assemble the Yard Master 2 WraithVeil® Dual screen.
◆
The WraithVeil® Dual is a 2-directional flexible vinyl projection screen material. It is designed to
accommodate either front or rear projection.
◆
Be sure to use the screen only during a light breeze (up to 7 mph); it is not meant to withstand heavy winds.
*Elite Screens is not responsible for damages due to negligence resulting from misuse under weather
conditions and will void your warranty.
◆
Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the points
below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆
After using the screen, disassemble it and store it in the carrying bag provided.
◆
To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry, assemble
and disassemble.
Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by several press stubs, which
ensure an evenly stretched and flat surface. The WraithVeil® Dual (front/rear projection) screen material is durable
and can be folded many times without causing damage or distortion to the surface.
Correct usage of the projection screen will ensure better viewing results.
For front projection, assemble and view the screen as indicated in Fig. 1.
For rear projection, assemble and view the screen as indicated in Fig. 2.
V04062020JA-Z
Yard Master 2 WraithVeil® Dual Series
180" Indoor/Outdoor Portable Projection Screen
Fig. 1
1
User's Guide – Z type
Fig. 2
www.elitescreens.com
Advertisement
Table of Contents
Related Manuals for Elite Screens YardMaster 2 WraithVeil Dual Series
Summary of Contents for Elite Screens YardMaster 2 WraithVeil Dual Series
- Page 1 Correct usage and maintenance will ensure a long product life. Care & Use Instructions ◆ Elite Screens highly recommends two people to assemble the Yard Master 2 WraithVeil® Dual screen. ◆ The WraithVeil® Dual is a 2-directional flexible vinyl projection screen material. It is designed to accommodate either front or rear projection.
- Page 2 Hardware and Parts List A. Folding frame x1 B. Left/Right folding legs x2 C. Center brace x1 (Adjustable) (Adjustable) D. Knob Screw E. Center brace foot F. Projection screen material x1 (Refer to Chart) (Refer to Chart) G. Screen material bag x1 Carrying Bag x1 I.
- Page 3 Next, screw the eyebolts (J) into the openings located at the top of the frame. Fig 6 Screen Material Attachment Take the screen material (F) out of the screen material bag (G) and align the corners of the screen material with the inside corners of the frame.
- Page 4 2. Lay the frame on its backside on clean surface, then lay the legs over on the frame in the position desired. Fig 10 Location points for legs 3. Once you have aligned the leg’s holes with the frame’s holes, secure with the knob screws. Fig 11 Fig 12 Warning:...
- Page 5 Be sure to place folding frame, legs, and smaller parts into the carrying bag first and place the material on top to keep material from creasing or tearing. For more information, technical support or your local Elite Screens contact, please visit www.elitescreens.com...
