Yard Master Pro B Series
Indoor/Outdoor Portable Projection Screen
Thank you for choosing the Yard Master Pro portable projection screen! Please read through this user
guide before utilizing the screen. Correct usage and maintenance will ensure a long product life
For a visual demonstration of the assembly and disassembly for the
Yard Master Pro (Models under 150"), please view our video at:
http://www.elitescreens.com/ympro_assembly
OR scan the QR Code provided:
Care & Use Instructions
◆ Elite highly recommends two people to assemble the Yard Master Pro screen.
◆ Please be sure to distinguish between the front and back of the screen fabric when setting up the
projection screen. CineWhite® UHD (front projection) and Wraith Veil (rear projection) are both labeled
front, back.
◆Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the
points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆After using the screen, disassemble it and store it in the carrying bag provided.
◆To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry,
assemble and disassemble.
Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by several pegs
along the frame, which ensure an evenly stretched and flat surface. The CineWhite® UHD (front
projection) and Wraith Veil (rear projection) screen materials are durable and can be folded many times
without causing damage or distortion to the surface.
Rev. 090618
User's Guide
1
ELITESCREENS.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elite Screens Yard Master Pro B Series
Summary of Contents for Elite Screens Yard Master Pro B Series
- Page 1 Yard Master Pro B Series Indoor/Outdoor Portable Projection Screen User’s Guide Thank you for choosing the Yard Master Pro portable projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life For a visual demonstration of the assembly and disassembly for the Yard Master Pro (Models under 150"), please view our video at:...
- Page 2 Parts Diagram A. Folding frame x1 B. Left and right folding legs x2 C. Screen material bag x2 D. Projection screen material x2 E. Knob screw x6 F. Carrying Bag x1 CineWhite™ UHD (front projection)/Wraith Veil (rear projection) G. Rope with ring x4 H.
- Page 3 2. Next, unfold the smaller sections out. 3. Lastly, unfold one half of the frame from the other, as shown. Side View Note: When unfolding the frame and legs, be sure the latches on the hinges "click" into place. Please also make sure all 4 corners of the frame are at a 90°...
- Page 4 5. At the bottom of the legs, unfold the additional support sections as shown below. 6. Line up the correlating screw holes on the frame and legs and secure using the knob screws (E) provided. See below. Note: Be sure to place the legs in which the eye loops are facing outward from the frame.
- Page 5 7. To attach the screen material (D), first utilize the attached pull tabs at the corners to easily hook the holes on the material to the pegs on frame (1). Next, attach the middle sections of sides (2). Then, follow with the rest of the sections (3).
- Page 6 Screen Disassembly 1. Remove ropes (G) and stakes (H) from the ground. 2. Unlatch the hinged support bars on front side of each leg so that it is bent and fold that half of the legs up. Slowly lower the screen to the ground (towards the closed legs). Two people are needed for this step. 3.
- Page 7 7. Fold screen material (D) in half, folding the bottom of the screen towards the top. Then, fold in half again in the same way. Lastly, fold the material into thirds to condense the length and place it into the screen material bag (C).
