Yard Master Pro B Series
Indoor/Outdoor Portable Projection Screen
Thank you for choosing the Yard Master Pro portable projection screen! Please read through this user
guide before utilizing the screen. Correct usage and maintenance will ensure a long product life
For a visual demonstration of the assembly and disassembly for the
Yard Master Pro (150"/180" Models), please view our video at:
http://www.elitescreens.com/ympro150-180_assembly
OR scan the QR Code provided:
Care & Use Instructions
◆ Elite highly recommends two people to assemble the Yard Master Pro screen.
◆ Please be sure to distinguish between the front and back of the screen fabric when setting up the
projection screen. CineWhite® UHD (front projection) and Wraith Veil (rear projection) are both labeled
front, back.
◆Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the
points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆After using the screen, disassemble it and store it in the carrying bag provided.
◆To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry,
assemble and disassemble.
Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by several pegs
along the frame, which ensure an evenly stretched and flat surface. The CineWhite® UHD (front
projection) and Wraith Veil (rear projection) screen materials are durable and can be folded many times
without causing damage or distortion to the surface.
Rev. 090618
150"/180" Models
User's Guide
1
ELITESCREENS.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elite Screens Yard Master Pro B Series
Summary of Contents for Elite Screens Yard Master Pro B Series
- Page 1 Yard Master Pro B Series 150"/180" Models Indoor/Outdoor Portable Projection Screen User’s Guide Thank you for choosing the Yard Master Pro portable projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life For a visual demonstration of the assembly and disassembly for the Yard Master Pro (150"/180"...
- Page 2 Parts Diagram A. Folding frame x1 B. Left and right folding legs x2 C. Center Support Leg x1 (180" models only) D. Projection screen material x2 E. Screen material bag x2 F. Carrying Bag x1 CineWhite® UHD (front projection) Wraith Veil (rear projection) Knob screw x8 G.
- Page 3 2. Next, unfold the horizontal sections by separating and pulling the left and right sides outwards. Note: When unfolding the frame and legs, be sure the latches on the hinges "click" into place. Please also make sure all 4 corners of the frame are at a 90° angle and the hinged support bar is straight and not bent. Screen Material Attachment Rev.
- Page 4 3. To attach the screen material (D), first utilize the attached pull tabs at the corners to easily hook the holes on the material to the pegs on frame (1). Next, attach the middle sections of sides (2). Then, follow with the rest of the sections (3).
- Page 5 7. Carefully take the center support leg (C) out of the carrying bag (F) and unfold it completely. Note: If you are planning to use the Wraith Veil rear projection material (D), attach the short center support leg (J) instead of the center support leg (C). 6.
- Page 6 10. At least two people are needed for this step. Open the front side of each folding leg (B) and carefully lift the top of the frame to stand up the screen. While keeping a hold on the screen, open the other side of each folding leg and fasten the last knob screws (I) on the back sections of the legs and frame.
- Page 7 4. Loosen and remove the ropes (G) and knob screws (I) from each leg. This step is for 180" models only. 5. Fully tighten the knob at the bottom of the center support leg (B). Remove the leg, fold and place it inside the carrying bag (F) provided.
- Page 8 10. Press in the black locking buttons, near the folding joints, and carefully fold the frame. 11. Store the screen in the provided carrying bag (F). Be sure to place folding frame, legs, and smaller parts into the carrying bag first and place the material on top to keep material from creasing or tearing. For more information, technical support or your local EliteScreens contact, please visit ELITESCREENS.com...
