Westin Automotive Products, Inc.
5200 N. Irwindale Ave. Ste 220
Irwindale, Ca 91706
8/26/09
INSTRUCTIONS—INSTRUCCIONES—CONSIGNES
APPLICATION: 2007-2010 FORD EXPEDITION
GRILLE GUARD ASSEMBLY
LOWER MOUNTING BRAKET(2) DRIVERS SIDE (3) PASSENGER SIDE
UPPER MOUNTING BRAKETS-A (3) DRIVERS SIDE, (4)PASSENGER SIDE
UPPER MOUNTING BRAKETS-B (5) DRIVERS SIDE, (6) PASSENGER SIDE
DOUBLE NUT PLATE
M10 X 25MM BUTTON HEAD BOLTS
M10 X 25MM HEX HEAD BOLTS
M10 X 30MM HEX HEAD BOLTS
M10 FLAT WASHERS
M10 NYLOCK NUTS
M10 LOCK WASHERS
M12 X 30MM HEX HEAD BOLTS
M12 NYLOCK NUTS
M12 FLAT WASHERS
ASAMBLEA DEL PROTECTOR DE PARRILLA
SOPORTES DE MONTURA INFERIOR (2) LADO DEL CONDUCTOR (3) LADO DEL PASA-
JERO
SOPORTES DE MONTURA SUPERIOR-A (3) LADO DEL CONDUCTOR (4) LADO DEL
PASAJERO
SOPORTES DE MONTURA SUPERIOR-B (5) LADO DEL CONDUCTOR (6) LADO DEL
PASAJERO
DOBLE PLANCHA DE TUERCA
PERNOS DE CABEZA DE BOTON M10 25MM
PEERNOS DE CABEZA DE AOJO M10 X 25MM
PERNOS DE CABEZA DE AOJO M10 X 30MM
RONDANAS PLANAS M10
TUERCAS NYLOCK M10
RONDANAS DE CANDADO M10
PERNOS DE CABEZA DE AOJO M12 X 30MM
TUERCAS NYLOCK M12
RONDANAS PLANAS M12
ASSEMBLAGE GRILLE DE PROTECTION
SUPPORT DE MONTAGE INFERIEUR (2) COTE CONDUCTEUR, (3) COTE PASSAGER
SUPPORTS DE MONTAGE SUPERIEURS -A (3) COTE CONDUCTEUR, (4) COTE PASSA-
GER
SUPPORTS DE MONTAGE SUPERIEURS -B (5) COTE CONDUCTEUR, (6) COTE PASSA-
GER
PLAQUE D'ECROU DOUBLE
M10 X 25MM BOULONS A TETE BOUTON
M10 X 25MM BOULONS A TETE HEXAGONALE
M10 X 30MM BOULONS A TETE HEXAGONALE
M10 RONDELLES PLATES
M10 ECROUS NYLSTOP
M10 RONDELLES-FREIN
M12 X 30MM BOULONS A TETE HEXAGONALE
M12 ECROUS NYLSTOP
M12 RONDELLES PLATES
PART NUMBER: 40-2405, 45-2400
DESCRIPTION
1
TOOLS NEEDED
15MM SOCKET
15MM WRENCH
18MM SOCKET
18MM WRENCH
RATCHET
TORQUE WRENCH
DADO 15MM
LLAVE 15MM
LLAVE 18MM
LLAVE 18MM
MATRACA
LLAVE DE TORCION
15MM DOUILLE
15MM CLE
18MM DOUILLE
18MM CLE
CLE A CLIQUET
DYNAMOMETRIQUE
Thank You for choosing Westin products
For additional installation assistance please call
Customer Service (800)793-7846
75-0936
