EN
• Repairs may only be carried out by a skilled person using
original spare parts and accessories.
• If the mains connection cable is damaged, it must be
replaced by a skilled person.

Product description

System description

The sanitary module is equipped with user detection, an odour extraction unit and an
orientation light.
Soft-touch buttons are integrated in the cistern lid and can be used to release a large or small
flush or activate the odour extraction unit.
The integrated odour extraction unit neutralises unpleasant odours in the WC ceramic
appliance.
Technical data and conformity

Technical data

Nominal voltage
Mains frequency
Operating voltage
Power consumption
Power consumption standby
Mains connection
Flow pressure range
Flush volume, factory setting

Declaration of conformity

You can obtain a copy of the declaration of conformity from your responsible Geberit sales
company.
12
100–240 V AC
50–60 Hz
4.1 V DC
5 W
< 0.5 W
Direct connection via system plug with
flexible three-wire sheathed cable
0.1–10 bar
10–1000 kPa
6 and 3 l
3621388427-1 © 09-2017
968.239.00.0 (00)
