Easidew Portable HP User's Manual

NOTE: Connect the machined ferrule end before

connecting the tube adaptor end

4. Insert the tube adaptor until it rests firmly on

the shoulder of the Swagelok

Finger-tighten the nut.

5. Mark the nut at the 6 o'clock position. While holding

the fitting body steady, tighten the nut 1¼ turns to the

9 o'clock position.

Michell Instruments

tube fitting body.

Swagelok

Figure 1

September 2010, R4 MS-12-12

Fitting Instructions

INSTALLATION
