Easidew Portable HP User's Manual
If the front panel prevents the connector from fitting onto the sensor, follow the
instructions below:
•
Completely unscrew the cable gland on the GDSN connector to release
the cable tension.
•
Remove the locking screw from the back of the connector (retaining the
metal O-ring).
•
Remove the connector block using a small screwdriver.
•
Rotate the connector block and push it back into the connector housing.
Take care not to trap any wires against the hole for the locking screw.
Michell Instruments
MAINTENANCE
11
