3.4 OVERALL DIMENSIONS

5.50
(140 mm)
8.25
(210 mm)
14.00
(360 mm)
18.00
(460 mm)
Manual Tornado Monitor Dimensions
CONTINUOUS
90°
See table below for additional height
from Inlet Fitting
Fig 3.4A
MODEL INLET FITTING
TYPE
Y2-*1*A 2-1/2" - 7.5 NH FEMALE
(no inlet fitting)
Y2-*2*A 2-1/2" - 11 BSP FEMALE
Y2-*3*A 2.0" - 11.5 BSP FEMALE
Y2-*6*A 2.5" ANSI 150 FLANGE
Y2-*7*A 2-1/2" - 8 NPT FEMALE
Y2-*8*A 2.0" - 11.5 NPT FEMALE
Y2-*9*A 3.0 - 8 NPT FEMALE
Y2-*L*A TFT CODE-RLF
(fits Extend-A-Gun RC3)
360°
8.25
(210 mm)
45°
16.50
(420 mm)
12.40
(315 mm)
Electric Tornado RC Monitor Dimensions
ADDITIONAL
HEIGHT
0.00"
0 mm
2.00"
51 mm
1.50"
38 mm
2.00"
51 mm
2.00"
51 mm
1.50"
38 mm
2.44"
62 mm
2.00"
51 mm
6
185° LEFT
185° RIGHT
90°
45°
See table below for additional height
from Inlet Fitting
Fig 3.4B
12.40
(315 mm)
