3.3 INLETS AND OUTLETS

Available inlets and outlets are shown below and should be specified at time of order.
MANUAL TORNADO (TILLER BAR) MODEL MANUAL TORNADO (TILLER BAR) MODEL
2.5" BSP 2.5" BSP 2.0" BSP 2.0" BSP
FEMALE FEMALE FEMALE FEMALE
(Y2405A) (Y2405A) (Y2425A) (Y2425A)
2.5" NH 2.5" NH
MALE MALE
(Y2320ANJ) (Y2320ANJ)
INLET COUPLING INLET COUPLING
2.5 - 7.5 NH 2.5 - 7.5 NH
2.5" ANSI 150 2.5" ANSI 150 2.5" NPT 2.5" NPT
(Y2430A) (Y2430A) FEMALE FEMALE
(Y2400A) (Y2400A)
Fig 3.3
Inlets and Outlets
5
1.5" NH 1.5" NH 2.5" BSP 2.5" BSP
MALE MALE MALE MALE
(Y2420ANF) (Y2420ANF) (Y2420ABJ) (Y2420ABJ)
TORNADO RC MODEL TORNADO RC MODEL
2.0" NPT 2.0" NPT
FEMALE FEMALE
(Y2420A) (Y2420A)
3.0" NPT 3.0" NPT CODE-RLF CODE-RLF
FEMALE FEMALE (Y2413A) (Y2413A)
(Y2403A) (Y2403A)
