YE-RF-900 Wireless Operator Station, 900 MHz
The Wireless Operator Station is radio linked to the monitor so that the operator can control the water discharge from the
best vantage point. This operator station gives the user full control of the monitor including the STOW, OSCillate, and any
AUXiliary functions. Every TFT RC monitor is shipped with the receiver and antenna pre-mounted in the monitor control
box. All the user needs to do is mount the storage bracket and teach the ID code to the handheld unit.
The range of the wireless operator station is 500 ft (152 m) and the handheld unit is powered by four (4) AA batteries,
lithium batteries are recommended. Lithium batteries will provide 33 hours of continuous operation. When the battery
voltage falls below a set level, the POWER led will begin to flash. At this point there is ~3 hours of continuous operation
remaining. Other battery types will significantly reduce operating time and unit reliability.
The handheld unit will automatically turn off after 5 minutes if no buttons are pressed.
1.0 SPECIFICATIONS:
Handheld Unit Batteries
Transmitting Power
Operating Range
Operating Frequency
Agency Approvals
1.1 TEACHING ID CODE:
Every monitor has a unique ID code that must be "taught or transferred" to the handheld unit. This unique ID code allows
multiple monitors to be used in one location without interference. Perform the following procedure to teach the handheld
unit.
On Handheld Unit:
-Press POWER button to turn on electronics.
-Press and hold both LEFT & RIGHT buttons for 5 seconds.
-Continue to press LEFT & RIGHT buttons and then press UP button for 2 seconds.
-Release buttons. OSC & STOW leds will flash rapidly to indicate that the unit is in teach mode.
On Monitor Control Box:
-Apply power to monitor.
-Press and hold both LEFT & RIGHT buttons for 5 seconds.
-Continue to press LEFT & RIGHT buttons and then press UP button for 2 seconds.
-Release buttons. OSC & STOW leds will flash rapidly to indicate that the unit is in teach mode.
-OSC & STOW leds on handheld unit will stop flashing after ID code is transferred.
-Press DOWN button on monitor control box to exit teach mode.
-Cycle power off and back on to monitor.
TASK FORCE TIPS, Inc.
MADE IN USA • www.tft.com
©Copyright Task Force Tips, Inc. 2006
Addendum
RC Monitor Installation Manuals
LIY-200, LIY-300, LIX-300
Four (AA) Batteries, Lithium Recommended
900 MHz (902-928 MHz)
FCC Part 15.247
Industry Canada (IC)
Europe
2800 E. Evans Ave, Valparaiso, IN 46383-6940 USA
800-348-2686 • 219-462-6161 • Fax 219-464-7155
100mW
500 ft (152m)
OUR9XSTREAM
4214A-9XSTREAM
N/A
LIY-ADD4 December 13, 2006 Rev 00
