5.5.2.2 Wiring to a Primary Operator Station

The joystick cable will enter the primary operator station through the connector labeled WIRELESS OPER. STATION. Refer to
section 5.1.2D.
Function
UP
DOWN
LEFT
RIGHT
COMMON

5.6 TOGGLE SWITCH MONITOR OPERATOR STATION

This operator station allows the monitor to be controlled by three toggle switches. The installer will need to mount the operator station
and connect the cable to a primary operator station or directly to the monitor.

5.6.1 ENCLOSURE MOUNTING

Select proper operator location. Enclosure is
designed to be surface mounted and the size is
5" x 3 1/8" (127 x 80mm). Height to top of
switches is 3 1/8" (80mm). Refer to Figure 5.6.1
for mounting hole dimensions.
5.6.2 ELECTRICAL WIRING
See section 5.1.2C.
**WATER VALVE CONNECTION **
-TRIGGER ACTUATION SWITCHES
ORANGE WIRE TO GROUND
- 5 AMP SWITCH CONTACT RATING
- WHEN SWITCHING A RELAY OR SOLENOID,
INSTALL A SUPPRESSION DIODE
Joystick
Cable Color
Do not connect 12VDC to
Grey
Primary Operator Station
Black/White
inputs. This will result in
damage to the
Tan
communication board.
Pink
Red
Fig 5.5.2.2
Joystick Operator Station Wiring
to Primary Operator Station
MOUNT ENCLOSURE
WITH (2) 1/4-20 FASTENERS.
TIGHTEN SECURELY.
NOTE
Function
STREAM
FOG
TRIGGER
n/u
n/u
n/u
n/u
n/u
16
INSTALLER SUPPLIED CABLE
O.D. RANGE .16" - .31"
RECOMMEND: 7 CONDUCTOR, 20 AWG,
UNSHIELDED CONTROL CABLE
CONSULT FACTORY FOR LENGTHS
EXCEEDING 500 FT (150 m)
Joystick
Cable Color
Blue
Green
Orange
White
Brown
Black
Purple
Yellow
4.45
(113 mm)
Figure 5.6.1
Toggle Switch Operator Station
Hole Dimensions
