Melink Intelli-Hood Controls Reference Manual page 55

GE/Fuji AF-300 C11 Series VFD
FUNC # SETTING
F00 1 DATA PROTECTION (0 = Allows Data Changing, 1 = Lock Settings)
F01 3 FREQUENCY COMMAND (3 = Frequency Signal Through Terminal Input)
F02 2 OPERATION COMMAND (2= Fwd Run Command Through Terminal Input, STOP key inactive)
F03 60 MAXIMUM FREQUENCY (in Hz) (Set to 60 for USA, 50 for EU)
F04 60 BASE FREQUENCY (in Hz) (Set to 60 for USA, 50 for EU)
F07 30 ACCELERATION TIME (in seconds)
F08 30 DECELERATION TIME (in seconds)
F09 1 TORQUE BOOST (1 = Normal Fan Application)
F10 1 ELECTRONIC THERMAL OVERLOAD OPERATION (1 = Active for General-Purpose Motor)
F11 AMPS ELECTRONIC THERMAL OVERLOAD LEVEL (Set to Motor FLA in Amps)
F12 5 ELECTRONIC THERMAL OVERLOAD TIME (in seconds)
F14 3 RESTART AFTER MOMENTARY POWER FAILURE (3 = Restart Active at Starting Frequency)
F15 60 FREQUENCY HIGH LIMIT (in Hz)
F16 0 FREQUENCY LOW LIMIT (in Hz)
F17 0 FREQUENCY GAIN (0 = For 0 to +10VDC)
F18 0 FREQUENCY BIAS (in Hz)
F20 3 DC INJECTION BRAKE (Starting Frequency in Hz)
F21 0 DC INJECTION BRAKING LEVEL (in Percent)
F22 0 DC INJECTION BRAKING TIME (0 = Inactive)
F23 1 STARTING FREQUENCY (in Hz)
F25 1 STOP FREQUENCY (in Hz)
F26 2 MOTOR SOUND (Higher C.F. = Lower Audible Noise + Greater Adverse Effects on Motor)
F27 0 MOTOR TONE
F30 100 METER ADJUSTMENT (in Percent)
F31 0 METER OUTPUT (0 = Frequency in 0-10V Scale)
F36 0 30Ry OPERATION MODE (0 = Excited When Tripped)
E01 0 X1 TERMINAL FUNCTION (0 = Multi-Step Frequency set in C05)
E02 1 X2 TERMINAL FUNCTION (1 = Multi-Step Frequency set in C06) (Jumper X2-CM)
E03 4 X3 TERMINAL FUNCTION (4 = External Alarm Trip THR) (Jumper X3-CM)
C05 60 MULTI-STEP FREQUENCY 1 (in Hz)
C06 0-60 MULTI-STEP FREQUENCY 2 (Set to Air Balance Speed in Hz) [60 is Melink Default]
P00 2 MOTOR CHARACTERISTICS
H01 0 OPERATION TIME ACCUMULATION
H02 --- TRIP HISTORY
H03 0 DATA INITIALIZATION (0 = Inactive, 1 = Reset to Factory Default Values)
H04 1 AUTO RESET (1 = Active with 5 Attempts)
H06 1 FAN STOP OPERATION (1 = Active)
H20 0 PID CONTROL (0 = Inactive)
Notes:
Program Function Code Settings
Bob Evans EMS Application
Prog_C11.123
4-13
DESCRIPTION
07/11/00
