Melink Intelli-Hood Controls Reference Manual page 44

GE/Fuji AF-300 Micro-Saver II Series VFD
FUNC # SETTING
F00 1 DATA PROTECTION (0 = Allows Data Changing, 1 = Lock Settings)
F01 1 FREQUENCY COMMAND (1 = Frequency Signal Through Terminal Input)
F02 2 OPERATION COMMAND (2 = Fwd Run Command Through Terminal Input, STOP key inactive)
F03 60 MAXIMUM FREQUENCY (in Hz) (Set to 60 for USA, 50 for EU)
F04 60 BASE FREQUENCY (in Hz) (Set to 60 for USA, 50 for EU)
F05 VOLTS MAXIMUM OUTPUT VOLTAGE (Set at motor rated volts: 208, 220, 230, 380, 400, 460 ,480)
F06 5 ACCELERATION TIME (in seconds)
F07 60 DECELERATION TIME (in seconds)
F08 1 TORQUE BOOST (1 = Normal Fan Application)
F09 85 METER ADJUSTMENT (Adjusts the Full Scale Voltage Level)
F10 4 MOTOR POLES (4 = Standard 4-Pole Motor)
F12 2 MOTOR SOUND (Higher C.F. = Lower Audible Noise + Greater Adverse Effects on Motor)
F13 5 RESTART ATTEMPTS (5 = 5 Restarts)
F14 4 RESTART AFTER MOMENTARY POWER FAILURE (4 = Restart Active, Resume at Last Freq)
F15 1 ELECTRONIC THERMAL OVERLOAD OPERATION (1= Active)
F16 AMPS ELECTRONIC THERMAL OVERLOAD LEVEL (Set to Motor Rated FLA)
F17 0 DC BRAKE (0 = Inactive)
F21 60 MULTI STEP SPEED 1 (Set to Bypass Speed in Hz)
F28 1 S-CURVE ACC/DEC (1 = Weak S-Curve)
F29 -- FAULT MEMORY
F31 180 TORQUE LIMIT ACC/DEC (180 = Limit to 180%)
F32 180 TORQUE LIMIT CONSTANT (180 = Limit to 180%)
F34 0 BIAS FREQUENCY (0 = no offset)
F35 100 GAIN FOR FREQUENCY SIGNAL (in Percent of Maximum Frequency)
F36 0-60 HIGH LIMITER (Set to Air Balance Speed in Hz) [60 is Melink default]
F37 0 LOW LIMITER (in Hz)
F39 0 DATA INITIALIZATION (0 = Inactive, 1 = Reset to Factory Default Values)
F40 0 MONITORING SIGNAL (0 = Analog Signal to FMA Terminal)
F41 0 FMA TERMINAL (0 = Display Output Frequency)
F54 0 Y1 TERMINAL (0 = Drive Running State)
F57 0 THR TERMINAL (0 = Trip Function) (Jumper THR-CM)
F69 0 AUTOMATIC TORQUE VECTOR CONTROL (0 = Inactive)
Notes: 1. If trouble starting high inertia fans or operating at low speed, may need to increase
torque boost F08 gradually to about 4. Keep as low as possible.
2. If problems with OU faults on high inertia fans, increase strength of s-curve with F28=2.
Program Function Code Settings
Intelli-Hood Application
Prog_MSII.123
4-2
DESCRIPTION
06/23/00
