Melink Intelli-Hood Controls Reference Manual page 30

GE Micro$averII Drive Terminal Connections
GE/FUJI
MICRO-SAVER II
30A
Color
Red
Black
White
Blue
Yellow
Orange
Brown
External Trip Jumper Connected Between THR and
CM
60.00
PRG
RESET
FUNC
DATA
30B Y1 FMA PLC BX RST C1 13 12 11
30C FMP X1 X2 X3 X4 REV FWD THR
L1 L2 L3
Terminal Pin
C1
FMA
FWD
X1
11
CM
12
RUN
STOP
CM
U V
W
Purpose
1 4-20 mA
2 0-10 VDC Out
3 Run Command
4 Bypass Command
5 Signal Common
6 FWD/Bypass Common
7 0-10 VDC In
3-2
