Melink Intelli-Hood Controls Reference Manual page 24

Operation/Service Specifications for Melink Intelli-Hood Operator
Output Wire Lengths
Due to possibility for interference, the distance between the drive output and the motor being controlled
must be less than a specified distance. If the distances specified below must be exceeded, an output
filter must be installed on the application. When installing output filters, the filters should be as close to
the drive as possible and must be installed no farther than 15 feet (4.5 m) from the drive in order to be
effective. Installing the filters farther away than 15 feet will cause the filters to absorb the harmonics and
voltage spikes, causing them to fail prematurely.
GE P11 Drives
Drives 7.5 HP and larger
Motor Insulation Level
460 VAC Input Voltage
230 VAC Input Voltage
* For this case the cable length is determined by secondary effects and not voltage spiking.
Drives 5 HP and smaller
Motor Insulation Level
460 VAC Input Voltage
230 VAC Input Voltage
* For this case the cable length is determined by secondary effects and not voltage spiking.
Drives In General
Input Voltage
208/230 VAC
460 VAC
680 VAC
1000V 1300V
66 ft (20 m) 328 ft (100 m)
1312 ft (400 m) * 1312 ft (400 m) *
1000V 1300V
66 ft (20 m) 165 ft (50 m) *
328 ft (100 m) * 328 ft (100 m) *
Distance
200 ft (61 m)
66 ft (20 m)
45 ft (14 m)
2-8
1600V
1312 ft (400 m) *
1312 ft (400 m) *
1600V
165 ft (50 m) *
328 ft (100 m) *
