Melink Intelli-Hood Controls Reference Manual page 45

GE/Fuji AF-300 P11 Series VFD
FUNC # SETTING
F00 1 DATA PROTECTION (0 = Allows Data Changing, 1 = Lock Settings)
F01 3 FREQUENCY COMMAND (3 = Frequency Signal Through Terminals 12 and/or C1)
F02 2 OPERATION COMMAND (2= Fwd Run Command Through Terminal Input, STOP key inactive)
F03 60 MAXIMUM FREQUENCY (in Hz) (Set to 60 for USA, 50 for EU)
F04 60 BASE FREQUENCY (in Hz) (Set to 60 for USA, 50 for EU)
F05 VOLTS RATED VOLTAGE - Set at motor rated volts (208, 220, 230, 380, 400, 460 ,480)
F06 VOLTS MAXIMUM VOLTAGE - Limits maximum outout voltage. Set to same as Rated Voltage F05.
F07 5 ACCELERATION TIME (in seconds)
F08 60 DECELERATION TIME (in seconds)
F09 0.1 TORQUE BOOST (0.1 = Normal Fan Application)
F10 1 ELECTRONIC THERMAL OVERLOAD OPERATION (1= Active for General-Purpose Motor)
F11 20 - 135% ELECTRONIC THERMAL OVERLOAD LEVEL (% = (Motor FLA)/(VFD Rated A)x100)
(Calculate Motor FLA as a Percentage of VFD FLA) [100 is Melink Default]
F12 5 ELECTRONIC THERMAL OVERLOAD TIME (in seconds)
F13 1 ELECTRONIC THERMAL OVERLOAD BRAKING (1 = Active for Built-In Resistor)
F14 3 RESTART AFTER MOMENTARY POWER FAILURE (3=Restart Active with Ride-Through)
F15 0-60 FREQUENCY HIGH LIMIT (Set to Air Balance Speed in Hz) [60 is Melink Default]
F16 0 FREQUENCY LOW LIMIT (in Hz)
F17 100 FREQUENCY GAIN (in Percent)
F18 0 FREQUENCY BIAS (in Hz)
F22 0 DC BRAKE (Braking Time) (0 = Inactive)
F26 2 MOTOR SOUND (Higher C.F. = Lower Audible Noise + Greater Adverse Effects on Motor)
F27 0 MOTOR TONE
F30 100 METER ADJUSTMENT (in Percent)
F31 0 METER OUTPUT (0 = Frequency in 0-10V Scale)
F40 150 DRIVING TORQUE LIMIT (in Percent)
F41 0 BRAKING TORQUE LIMIT (Automatic to Prevent OU Trip due to Regeneration Effect)
F42 0 AUTOMATIC TORQUE VECTOR CONTROL (0 = Inactive)
E01 0 X1 TERMINAL FUNCTION (0 = Multi-Step Frequency set in C05)
E02 9 X2 TERMINAL FUNCTION (9 = External Alarm Trip THR)
E03 8 X3 TERMINAL FUNCTION (8 = Alarm Reset)
C05 60 MULTI-STEP FREQUENCY 1 (Set to Bypass Speed in Hz)
P01 4 MOTOR POLES (4 = Standard 4-Pole Motor)
P02 kW MOTOR CAPCITY (Set to Motor Rated Capacity in kW)
P03 AMPS MOTOR CURRENT (Set to Motor Rated Current in Amps)
H03 0 DATA INITIALIZATION (0 = Inactive, 1 = Reset to Factory Default Values)
H04 5 AUTO RESET TIMES (5 = Five Reset Attempts)
H05 5 AUTO RESET INTERVAL (# of Seconds Between Attempts)
H07 1 ACC/DEC PATTERN (1 = Mild S-Curve)
H08 1 REVERSE LOCK (1 = Lock Reverse Operation)
H09 2 START MODE (2 = Smooth Restart Active)
H10 0 ENERGY-SAVING OPERATION (0 = Inactive)
Notes: 1. If problems with OU1, OU2, or OU3 fault on a high inertia fan; increase strength
of s-curve with H07 = 2.
2. For high inertia fans, may need to increase torque boost with F09 = 0.1 to 0.9.
3. Set SW1 switch to "Sink".
4. Set SW2 switch to "Off".
5. If problems with noise on drive terminals 12 or C1, may be able to eliminate with C33.
Setting range = 0.00 to 5.00 seconds. Higher value = lower noise + slower response.
Program Function Code Settings
Intelli-Hood Application
Prog_P11.123
4-3
DESCRIPTION
02/01/02
