parts list
ITEM QTY REFERENCE
Hardware: For Demo Board Only
1 4 E3, E4, E7, E8
2 4 E1, E2, E5, E6
3 2 J1, J2
4 0 J3-OPT
5 2 BP1, BP2, BP3, BP4
6 0.00058
7 4
ITEM QTY REFERENCE
DC2181A-A Required Circuit Components
1 0 R9
2 1 R10
3 1 U1
ITEM QTY REFERENCE
DC2181A-B Required Circuit Components
1 1 R9
2 1 R10
3 1 U1
PART DESCRIPTION
TURRET, 0.091˝
TURRET, 0.061˝
HEADER, 1PIN, 0.020˝ × 0.020˝
CONN, 3 PIN POLARIZED
CLEAR 0.200˝ × 0.440˝ BUMPER
3M, 0.5IN WIDE, 1/16IN THICK, DOUBLE SIDED FOAM
TAPE, 0.75IN × 0.50IN PIECE
STAND-OFF, NYLON, 0.375˝
PART DESCRIPTION
NO LOAD. SMD 0402
RES, CHIP, 0Ω JUMPER, 1/16W, 0402
400mA WIRELESS SYNCHRONOUS BUCK BATTERY
CHARGER, 3mm × 3mm QFN16
PART DESCRIPTION
RES, CHIP, 1.40M, ±1%, 1/16W, 0402
RES, CHIP, 1.05M, ±1%, 1/16W, 0402
400mA WIRELESS SYNCHRONOUS BUCK BATTERY
CHARGER, 3mm × 3mm QFN16
DEMO MANUAL
DC2181A-A/B
MANUFACTURER/PART NUMBER
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, TMM-101-02-L-S
HIROSE, DF3-3P-2DSA
KEYSTONE, 785-C
3M, 4466
KEYSTONE, 8832
MANUFACTURER/PART NUMBER
VISHAY, CRCW04020000Z0ED
LINEAR TECHNOLOGY, LTC4120EUD-4.2
MANUFACTURER/PART NUMBER
VISHAY, CRCW04021M40FKED
VISHAY, CRCW04021M05FKED
LINEAR TECHNOLOGY, LTC4120EUD
dc2181afa
