assemBly test proceDure
PS1
3.6V POWER SUPPLY
1A
Figure 5c. DC2181A-A/B Wireless Power Demo Board Mounted on PowerByProxi's ProxiPoint Transmitter
Note: All connections from equipment should be Kelvin connected directly to the
board pins which they are connected on this diagram and any input or output leads
should be twisted pair.
–
–
V
3.6 VM1
+
+
AM1
+ –
A
Figure 5a. DC2181A-A/B Wireless Power Demo Board Connection
Figure 5b. PowerByProxi's ProxiPoint Transmitter
