5 mm

4 mm

English

Seal the wall around the

plaster shield with water-

proof sealant (1).

Failure to seal the wall can

lead to possible water dam-

age.

Remove the flush insert screw using a 5 mm

Allen wrench ().

Remove the flush insert and seals.

Insert the function block.

Install and tighten the function block screws

using a 4 mm Allen wrench.

Measure the distance from the front of the

plaster shield to one of the screw-in flanges

("X").
