Johnson Controls IOM3711 Installation Manual page 2

Figure 1: IOM3711 physical features
Table 1: IOM3711 Physical features
Callo
Physical features: description and references
ut
1 Relay Output Terminal Blocks (See Table 2)
2 Mounting Clip
Device Address DIP Switch Block (See
3
addresses)
Universal Outputs (UOs) Terminal Blocks (See
4
Output terminal blocks)
5 24 VAC, Class 2 Supply Power Terminal Block (See Table 4)
Cover Lift Tab (See Removing the Expansion Module
6
cover)
Sensor Actuator (SA) Bus or Field Controller (FC) Bus
7
Terminal Block (See Table 4)
8 Universal Inputs (UI) Terminal Blocks (See Table 2)
9 Light-Emitting Diode (LED) Status Indicators (See Table 7)
Sensor Actuator (SA) Bus / Field Controller (FC) Bus Port
10
(RJ-12 6-pin Modular Jack) (See Table 4)
Mounting
Observe these guidelines when mounting an expansion
module:
• Ensure the mounting surface can support the
expansion module, DIN rail, and any user-supplied
enclosure.
• Mount the expansion module horizontally on 35 mm
DIN rail whenever possible.
• Mount the expansion module in the proper mounting
position (Figure 2).
2 IOM3711 Input/Output Module Installation Guide
• Mount the expansion module on a hard, even surface
• Use shims or washers to mount the expansion module
• Mount the expansion module in an area free of
Setting the device
• Provide for sufficient space around the expansion
Input and
• Do not mount the expansion module on surfaces prone
• Do not mount the expansion module in areas where
Observe these additional guidelines when mounting a
expansion module in a panel or enclosure:
• Mount the expansion module so that the enclosure
• Mount the expansion module so that the power
• Do not install the expansion module in an airtight
whenever possible in wall-mount applications.
securely and evenly on the mounting surface.
corrosive vapors and observe the Ambient Conditions
requirements in Table 10.
module for cable and wire connections for easy cover
removal and good ventilation through the expansion
module (50 mm [2 in.] minimum on the top, bottom,
and front of the expansion module).
to vibration, such as duct work.
electromagnetic emissions from other devices or wiring
can interfere with expansion module communication.
walls do not obstruct cover removal or ventilation
through the expansion module.
transformer and other devices do not radiate excessive
heat to the expansion module.
enclosure.
