IOM1711 and IOM2711 Input/Output Module Installation
Instructions
MS-IOM1711-0U, MS-IOM2711-0U
Application
The IOM1711 and IOM2711 input/output expansion
modules are part of the Metasys® system Field
Equipment Controller family. Input/Output Module (IOM)
expansion modules expand the number of points
connected to a Network Automation Engine (NAE), Field
Equipment Controller (FEC), VAV Modular Assembly
(VMA), or Advanced Application Field Equipment
Controller (FAC) to monitor and control a wide variety of
HVAC equipment.
IOM field controllers operate on an RS-485 BACnet®
MS/TP Bus and integrate into Johnson Controls® and
third-party BACnet systems.
Important: The MS-IOM171x-0U and MS-IOM271x-0U
models are used in Metasys Release 8.1
smoke control applications and are UL 864
UUKL/UUKLC 10th Edition Smoke Control
Listed. You must refer to the Metasys®
System UL 864 10th Edition
UUKL/ORD-C100-13 UUKLC Smoke
Control System Technical Bulletin
(LIT-12012487) for detailed requirements
and procedures for installing,
commissioning, and operating UL 864
UUKL/UUKLC Listed Metasys system
devices. The UL 864 UUKL/UUKLC listing
for Smoke Control Equipment is voided if
(1) you do not use the required software
tools at the required versions; or (2) you do
not meet the requirements or do not follow
the procedures as documented in the
Metasys® System UL 864 10th Edition
UUKL/ORD-C100-13 UUKLC Smoke
Control System Technical Bulletin
(LIT-12012487).
IOM1711 and IOM2711 Input/Output Module Installation Instructions
Part No. 24-10144-246, Rev. A
Note: With CCT Release 10.3 and Release Module (RM)
10.2, a new capability allows VMAs, FECs, and
FACs to communicate by using either the BACnet
or the N2 field bus networking protocol. The
operation of the IOM Input/Output Module is not
affected by the selection of the BACnet or the N2
protocol in the host controller when the IOM is
connected to the host controller using the SA bus.
Only the BACnet protocol is supported when the
IOM is connected directly to the trunk using the
FC bus.
North American Emissions
Compliance
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte toutes
les exigences du Règlement sur le matériel brouilleur
du Canada.
United States
This equipment has been tested and found to comply
with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when this equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area may cause harmful interference, in which
case the users will be required to correct the interference
at their own expense.
Software Release 8.1
Issued March 2018
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IOM1711 and is the answer not in the manual?

Questions and answers

Summary of Contents for Johnson Controls IOM1711

  • Page 1 IOM is connected directly to the trunk using the HVAC equipment. FC bus. IOM field controllers operate on an RS-485 BACnet® MS/TP Bus and integrate into Johnson Controls® and North American Emissions third-party BACnet systems. Compliance Important: The MS-IOM171x-0U and MS-IOM271x-0U models are used in Metasys Release 8.1...
  • Page 2: Installation

    To mount a field controller directly on a wall or other flat • Do not mount the controller in areas where vertical surface: electromagnetic emissions from other devices or wiring can interfere with controller communication. IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 3 4. Hold the controller in place, and insert the screws through the mounting clips and into the holes (or wall anchors). Carefully tighten all of the screws. Important: Do not overtighten the mounting screws. Overtightening the screws may damage the mounting clips. IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 4 Figure 3: IOM1711 and IOM2711 Physical Features Table 1: IOM17 and IOM27 Physical Features Callout Physical Feature: Description and References Device Address DIP Switch Block. See Setting the Device Addresses for more information. Mounting Clip 24 VAC, Class 2 Supply Power Terminal Block. See Table 5 for more information.
  • Page 5 Output Wiring Guidelines for more information. For detailed information on configuring and wiring an MS/TP Bus, FC bus, and SA bus, refer to the MS/TP Communications Bus Technical Bulletin (LIT-12011034). IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 6 Refer to the Metasys® System UL 864 10th Edition UUKL/ORD-C100-13 UUKLC Smoke Control System Technical Bulletin (LIT-12012487) for detailed requirements and procedures for installing, commissioning, and operating UL 864 UUKL/UUKLC Listed Metasys system devices. IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 7 Termination Details A set of Johnson Controls® termination diagrams provides details for wiring inputs and outputs to the controllers. See the figures in this section for the applicable termination diagrams. Table 2: Termination Details Type of Field Device Type of...
  • Page 8 Source (in Loop) Feedback from EPP-1000 Dry Contact UI or BI Incremental Control to Actuator (Switch Low, External Source) 24 VAC Binary Output (Switch Low, Externally Sourced) 24 VAC Binary Output (Switch High, Externally Sourced) IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 9 Termination Diagrams Input/Output Incremental Control to Actuator (Switch High, Externally Sourced) Analog Output (Current) 4–20 mA Output to Actuator Voltage (Analog Ouput) 4–20 mA Output to Actuator 0–10 VDC Output to Actuator (External Source) IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 10 Inputs/outputs with cables less than 30 m (100 ft) typically do not require an offset in the software setup. Cable runs over 30 m (100 ft) may require an offset in the input/output software setup. IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 11 Table Internal 12 V, 15k ohm pull up Qualified Sensors: 0-2k ohm potentiometer, RTD (1k Nickel [Johnson Controls® sensor], 1k Platinum, and A99B Silicon Temperature Sensor) Negative Temperature Coefficient (NTC) Sensor (10k Type L, 10k JCI Type II, 2.252k Type...
  • Page 12 0.5 A maximum output current 1.3 A at 25% duty cycle 40 mA minimum load current (hold current) OCOMn Universal Output (UO) Common Same as OUT Isolated from all other terminal commons, including other UO Commons. IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 13 1/4 hp 120 VAC, 1/2 hp 240 VAC 360 VA Pilot Duty at 120/240 VAC (B300) 3 A Non-inductive 24–240 VAC CE Marking (-2 model only): 6 (4) A N.O. or N.C. only, 240 IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 14 (>30 V) Relay Outputs is determined by the load connected to the relay and local electrical codes. Figure 8: Maximum Wire Length for Low-Voltage (<30 V) Inputs and Outputs by Current and Wire Size IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 15 The SA Bus and FC Bus wiring recommendations in this table are for MS/TP bus communications at 38,400 baud. For more information, refer to the MS/TP Communications Bus Technical Bulletin (LIT-12011034). IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 16: Setup And Adjustments

    ON and a device address from 4 to 127 is connected to a wired field bus, the entire field bus is rendered inoperable until the controller is disconnected or switch 128 is set to Off. IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 17 On Steady = Device Fault; no application loaded; Main Code download required, if controller is in Boot mode. Blink - 2 Hz = Download or Startup in progress, not ready for normal operation IOM1711 and IOM2711 Input/Output Module Installation Instructions...
  • Page 18: Repair Information

    Repair Information The MS-IOM1711-0U and MS-IOM2711-0U models are UL 864 10th Edition UUKL/ORD-C100-13 UUKLC listed for smoke control. If a controller fails to operate within its specifications, contact the Johnson Controls Repair Center in Louisville, Kentucky, at 1-502-671-7312. Accessories Table 8 for controller accessories ordering information.
  • Page 19 UL Listed, File S4977, UL 864 UUKL/ORD-C100-13 10th Edition Listed, Smoke Control Units and Accessories for Fire Alarm Systems Europe: Johnson Controls declares that these products are in compliance with the essential requirements and other relevant provisions of the EC Directive and Low Voltage Directive.
  • Page 20 The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these specifications, consult the local Johnson Controls® office. Johnson Controls shall not be liable for damages resulting from misapplication or misuse of its products.
