- Page 1 1.5 TONNE TROLLEY JACK CTJ1500QL MODEL NO: PART NO: 7612633 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0320 - ISS 1...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Trolley Jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
5. DO NOT make any modifications to this jack or adjust any valves. 6. DO NOT use the jack if an oil leak is apparent. Consult your CLARKE dealer. 7. DO NOT try to lift more then the 3 Tonne rated load for the jack. -
Page 4: Unpacking And Assembly
UNPACKING AND ASSEMBLY 1. Loosen the thumbscrew in the yoke until the lower handle can be inserted fully into the handle socket. • The handle has a groove which should engage with the thumb screw once it is re-tightened. • The socket in the handle will engage with the jack control valve at the base of the yoke. -
Page 5: Operation
2. Pump the handle several times to purge air from the system. 3. Turn the control valve clockwise and test the jack. If efficiency is still low, check the oil level as described under Maintenance ON PAGE 6. The jack is now ready to use. OPERATION This jack incorporates a twin piston pump with a ‘quick lift’... -
Page 6: Maintenance
10. Ensure that the axle stands cannot move when supporting the load and are on firm, level ground. Use suitable wheel chocks to stop the vehicle from moving. 11. The jack may move slightly during operation. It is important therefore, that the floor is clean and completely free from debris. -
Page 7: General Care
• Oil can be topped up using Clarke Hydraulic Oil (p/n 3050830 1 litre). Never use brake fluid or instead of oil. • Take care not to move the handle while topping up the oil. 3. Replace the filler plug and cover plate and purge any air from the system. -
Page 8: Troubleshooting
Jack will not Release valve still Check and fully open release lower at all. closed. valve. If any of these remedies fail to restore your jack, consult your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 9: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: Component Parts - General Assembly
COMPONENT PARTS - GENERAL ASSEMBLY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 11 COMPONENT PARTS - GENERAL ASSEMBLY Description No Description Hydraulic ram assembly Lifting arm Universal joint assembly Saddle base pivot shaft Steel ball Circlip 14mm Oil plug Connecting bar Cotter pin 4dia x 4.5 Circlip 13mm Coupling connector Flat head socket screw M8x20 Socket screw M8x19.5mm Slide plate Handle socket...
