1 Hardware
1.1 conga-QMX8X and conga-QEVAL
The conga-QMX8X is designed according to Qseven
features application processors from the NXP i.MX 8X product family with up
to 4 GB LPDDR4 onboard RAM and 64 GB onboard HS400 eMMC 5.1. It is
available in commercial and industrial temperature range.
The conga-QEVAL is designed according to Qseven
supports both x86 and ARM modules. With this dual architecture support,
customers can test modules with different architectures on a single carrier
board, thereby reducing production cost and time. The customers need to
make sure the switches and jumpers for the shared pins are set correctly to
avoid possible malfunction or damage to the module/carrier board.
1.2

Set Content

Part # Name
007005 conga-QEVAL/Qseven 2.0
ARM Revision B.4
016591 conga-QMX8-X/PTT-QuadXP-
3G-LPDDR4 eMMC16
Revision X.1
016453 conga-QMX8/HSP-T
Revision X.1
48000023 RS232 adapter cable
10000285 MicroSDHC-Card UHS-I
011115 conga-LDVI/EPI
033331 cab-LVDV-DAT-34-15
052147 cab-LVDV-PWR-10-15
Note: Future conga-QEVAL revisions (B.5 and later) will provide improved SD
card compatibility and improved audio performance via a congatec specific
audio card. The current sample distribution set includes the conga-QEVAL
revision B.4 and does not include the congatec specific audio card.
Copyright © 2019 congatec AG
® specification 2.1 and
® specification 2.0 and
Description
Qseven 2.0 evaluation carrier board for ARM
based Qseven Modules.
Qseven 2.1 module with NXP i.MX8 QuadXPlus
processor (Prototype). 3GB LPDDR4 and 16GB
onboard eMMC HS400.
Heatspreader. All stand-offs are M2.5 threaded.
MOLEX 6-Pin PicoBlade to two D-SUB 9.
8GB - Kingston industrial SDCIT/EU Class 10
with preinstalled image.
LVDS to DVI converter board for digital flat
panels with onboard EEPROM.
15cm data cable LVDS to DVI adapter
15cm power cable LVDS to DVI adapter
Qty
1
1
1
1
1
1
1
1
