Hardware Overview

The heart of this breakout is the RV-8803 Real Time Clock module from Micro Crystal. In this section we'll cover most of the features and characteristics
of the RV-8803 and this breakout but if you are looking for a more thorough synopsis of the RV-8803, take a look through the Application Manual . The
table below lists some of the operating characteristics of the RV-8803.
Operating Voltage Range
Time Accuracy (Temp. Compensated -40° to +85°C)
Time Accuracy (Temp. Compensated +85° to +105°C)
Current Consumption
2
I C Address
Power
There are two primary ways to power the SparkFun Real Time Clock Module - RV-8803 (Qwiic). The best and easiest way is through the Qwiic
Connectors on either side of the board. When used with any of our Qwiic-enabled boards or our Qwiic Shields, this voltage will be 3.3V. The other power
input is the 3.3V pin broken out. The board also includes a 3V 47mAh battery in the 12mm coin cell battery holder on the back for backup power.
Characteristic
SparkFun Qwiic Shield for Thing Plus Hookup Guide
A short guide for assembling and using the SparkFun Qwiic Shield for
Thing Plus.
1.5V - 5.5V
+/-3 ppm
+/-7 ppm
240 nA (Typ.) to 350 nA
0x64
Value
