Using the Qwiic system, assembling the hardware is simple. All you need to do is connect your Real Time Clock Module - RV-8803 (Qwiic) to your
chosen development board with a Qwiic cable or adapter cable. Otherwise, you can use the I C pins broken out if you do not have a Qwiic connector on
your development board. If you are not using a Qwiic-enabled board, make sure your input voltage and logic are either running at 3.3V or you are running
both controller and RTC at the same logic level.
In order to use the full functionality of the RV-8803, you will want to solder to the EVI, INT, CLKOUT and CLKOE pins broken out on this board. If you are
not familiar with through-hole soldering, take a look at this tutorial:
How to Solder: Through-Hole Soldering
SEPTEMBER 19, 2013
This tutorial covers everything you need to know about through-hole soldering.
