Installation Clearances
IMPORTANT: If you are installing your garage refrigerator under a
workbench, allow a minimum of 1
the refrigerator and the bottom of the workbench.
1
2
3
1. Workbench
2. 1
in. (30 mm) minimum space
3. Refrigerator

Electrical Requirements

WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or electrical shock.
Before you move your refrigerator into its final location, it is important
to make sure you have the proper electrical connection:
Recommended grounding method
A 115 Volt, 60 Hz., AC only 15 or 20 ampere fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet that
cannot be turned off by a switch. Do not use an extension cord.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, turn the control to the off position as shown
and then disconnect the refrigerator from the electrical source.
1. Off position
When you are finished, reconnect the refrigerator to the electrical
source and reset the control to the desired setting. See "Using the
Control."
4
in. (30 mm) between the top of

INSTALLATION INSTRUCTIONS

Unpack the Refrigerator

WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
1. Remove the refrigerator shipping carton, flatten it, and place it
next to the refrigerator on the floor.
2. Unpack accessories and hardware from the small box. Verify
contents. See "Tools and Parts."
3. Untape and open the refrigerator door to remove the shelves and
the installation instructions. Follow the instructions for proper
assembly.
4. Retape the refrigerator door to keep it closed until the handle
installation is complete.

Install the Caster Plate

WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
IMPORTANT:
Always lay the refrigerator on its side during the caster plate
installation. If you lay the refrigerator on its back, you can
damage the refrigerator.
Never place refrigerator on its top. It may damage the
compressor.
Allow the refrigerator to sit on its casters for 4 hours before
plugging into an electrical outlet.
1. Using 2 or more people, lay the refrigerator on its side.
