Adjusting the refrigerator
shelves...
Shelves can be adjusted
to match the way you use
To remove
shelves:
your refrigerator.
1.
Tilt up at front.
2. Lift up at back.
3. Pull shelf straight
out.
To replace
shelves:
I. Guide
the rear hooks into the slots in the shelf
supports.
2. Tilt up front of shelf until hooks drop
into slot.
Lower front of shelf to level position.
Removing and adjusting the freezer shelf...
To remove
the shelf:
1. Lift front slightly.
2. Lift back off supports.
3. Replace
in reverse order.
To adjust
the shelf:
1. Remove
shelf.
2. Remove
supports
by sliding
upwards,
3. Replace
supports
on desired
level.
4. Replace
shelf.
Removing the crispers and crisper cover...
PULL OUT TO THE STOP, LIFT THE FRONT
AND PULL AGAIN.
To remove
the crispers:
1. Slide crisper straight out to the stop, lift front, then
slide the rest of the way out.
REMOVE THE
GLASS INSERT,
LlFl THE FRAME FR
THEN THE BACK.
Moving the meat drawer and cover
. . .
2. Replace
in reverse order.
To remove
the cover:
1. Push up glass insert from bottom, then slide out
with both hands.
2. Lift front of cover frame.
3. Lift out cover frame by pulling
up and out.
4. Remove
metal cover support
To replace
the cover:
1. Replace
metal cover support
on wall supports
in front section
of cabinet.
2. Fit back of corner
into notch supports
on walls of
refrigerator,
then lower into place.
3. Slide back of glass insert into place,
then lower
front.
PULL OUT TO THE STOP, LIFI THE
FRONT AND PULL AGAIN.
To remove
the meat
drawer:
1. Slide the meat drawer
out to the stop.
2. Lift the front.
3. Slide the drawer
the rest of the way out.
4. Replace
in reverse order.
To remove
the cover:
ss IS HEAVY. 1. Tilt front of cover up, lift at back, and pull straight
out.
6
2. Replace
in reverse order.
