Owners Installation, Operation, and Safety Manual
Digital Liquid Meter
Series 900DP – High Flow
Models with Intrinsically Safe Barrier:
900CDP, 900CDP1.5, 900CDPBSPT, 900CDP1.5BPST
Models without Intrinsically Safe Barrier
900CDPX, 900CDPX1.5, 900CDPXBSPT, 900CDPX1.5BSPT
Tuthill Corporation
8825 Aviation Drive
Fort Wayne, IN 46809
(260) - 747-7524
www.fillrite.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tuthill Fill-Rite 900DP Series
Summary of Contents for Tuthill Fill-Rite 900DP Series
- Page 1 Owners Installation, Operation, and Safety Manual Digital Liquid Meter Series 900DP – High Flow Models with Intrinsically Safe Barrier: 900CDP, 900CDP1.5, 900CDPBSPT, 900CDP1.5BPST Models without Intrinsically Safe Barrier 900CDPX, 900CDPX1.5, 900CDPXBSPT, 900CDPX1.5BSPT Tuthill Corporation 8825 Aviation Drive Fort Wayne, IN 46809 (260) - 747-7524 www.fillrite.com...
-
Page 2: Table Of Contents
Table of Contents Thank You! ..........................2 About This Manual ........................ 2 Safety Information ......................... 3 Installation ..........................3 Procedure for Meter Calibration .................... 4 Operating Instructions ......................5 Low Battery Warning ......................6 Storage ..........................7 Troubleshooting........................7 Fluid Compatibility ......................... 7 Assembly and Disassembly .................... -
Page 3: Safety Information
Safety Information WARNING! To insure safe and proper operation of your equipment, it is critical to read and adhere to all of the following safety warnings and precautions. Improper installation or use of this product can cause serious bodily injury or death! •... -
Page 4: Procedure For Meter Calibration
IMPORTANT! If you have purchased this meter as part of a “Kit”, the meter flange base is drilled with 4 holes. This allows the meter to be used with 300 and 700 series pumps. Line the meter bracket up for installation and insert the bolts in the two holes that align with the corresponding holes on the pump outlet. -
Page 5: Operating Instructions
10. Pressing and holding the CAL button for 2 seconds before dispensing into a container will cause the meter to skip a fill operation and only change the unit of measure. IMPORTANT! For maximum accuracy, try to get as close as possible to the dispensed volume without changing flow rate. -
Page 6: Low Battery Warning
IMPORTANT! When the meter is in the “Deep Sleep” mode, dispensing fluid will NOT turn the meter on. The meter will not display or accumulate any fluid that is dispensed while in “Deep Sleep” mode. • Pressing any button will turn the meter on when in deep sleep mode (fluid flow will not turn the unit on or cause it to exit deep sleep mode). -
Page 7: Storage
Storage If your meter is to be stored for a period of time, clean it thoroughly. This will help protect the meter from damage. Troubleshooting WARNING! To prevent possible ignition of a flammable or explosive atmosphere DO NOT use a voltmeter, or similarly powered tool or device during live maintenance. -
Page 8: Repair
Accessing the Batteries* WARNING! DO NOT replace the batteries in an explosive atmosphere! Potential spark during this procedure can create an explosion! WARNING! Batteries may ONLY be replaced with the following: Duracell MN1500 Duracell MX1500 Energizer E91 Incorrect battery selection presents a safety hazard. For access to the batteries* (2 AA cell batteries - Figure1) 1) Remove the four screws at the top and bottom of front bezel (Torx #T25). -
Page 9: Replacement Parts Information
Replacement Parts Information Replacement parts can be obtained through any authorized Fill-Rite dealer. Be sure to use only genuine Fill-Rite replacement parts for your service and maintenance needs. For a list of authorized dealers, please visit our web site at “www.fillrite.com”. WARNING! Substitution of parts may impair intrinsic safety. -
Page 10: Pulser Information
900 Series Digital Meters w/Pulser (w/Barrier) Certain 900 Series Digital Meters (model number suffix of DP) can be powered externally and are equipped with an integral electronic pulser unit for use with Fuel Management Systems. The Fuel Management System must be configured for current sinking or contact closure types of signals. -
Page 11: Internal And External Power
Internal Power (Battery Power) All 900DP Series Digital Meters are battery powered. The battery tray is located behind the faceplate (see illustration page 8). Power is supplied by two alkaline “AA” batteries. With normal use, these batteries should provide 2 – 4 years of service. The digital display has an integral warning of low battery level (see page 6 for details). -
Page 12: Wiring Information With Intrinsically Safe Barrier
Installation using the Intrinsically Safe Barrier WARNING! The instructions on this page are intended as an introduction to the proper wiring procedure for the Series 900DP Digital Meter. Detailed wiring instructions and information are included in the 4 page document labeled: “FILL- RITE SERIES 900DP METER, INTRINSICALLY SAFE FLOWMETER”... -
Page 13: Wiring Information Without Intrinsically Safe Barrier
Meter Installation (w/o Intrinsically Safe Barrier) WARNING! The instructions on this page are intended as an introduction to the proper wiring procedure for the Series 900DP Digital Meter. Detailed wiring instructions and information are included in the 4 page document labeled: “FILL- RITE SERIES 900DP METER, INTRINSICALLY SAFE FLOWMETER”... -
Page 14: Technical Specifications / Dimensions
Reed Switch Information (cabinet models only) WARNING! CONDITIONS FOR SAFE USE: The Remote Reed Switch Assembly Part No. SA000048-005 is provided with a non-metallic housing. Care must be taken to avoid ignition hazards due to potential electrostatic charging hazard. Technical Specifications and Information Dimensions: 6.75”... -
Page 15: Specific Conditions Of Use
Warranty Information Your quality Tuthill / Fill-Rite product carries a full manufacturers limited warranty. For terms and conditions of that warranty please visit www.fillrite.com. Tuthill Corporation recommends you retain your sales receipt as proof of purchase. - Page 16 Certification Information The following is a list of standards used to attain certification: IEC 60079-0, 6th ed., IEC 60079-11, 6th ed., IEC 60079-26, 2nd ed., EN 60079-0:12+A11:2013, EN 60079-11:2012, EN 60079-26:2007, CAN/CSA C22.2 No. 60079-0:11, CAN/CSA C22.2 No. 60079-11:14, UL 913, 7th ed. (Rev. 2011-09-23), UL 60079-0, 5th ed., UL 60079-11, 5th ed., CAN/CSA C22.2 No.
