NanoStationM/locoM Series Quick Start Guide
Package Contents
NSM2/NSM3/NSM365/NSM5
NanoStation M 2/M3/M365/M5
Power Cord
locoM2/locoM5
NanoStationloco M 2/M5
https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]
NanoStationM/locoM Series Quick Start Guide
Zip Tie
Zip Tie
PoE (24V, 0.5A) with Mounting
Bracket
PoE (24V, 0.5A) with Mounting
Bracket
Advertisement
Table of Contents
Related Manuals for Ubiquiti NanoStationM Series
Summary of Contents for Ubiquiti NanoStationM Series
- Page 1 NanoStationM/locoM Series Quick Start Guide NanoStationM/locoM Series Quick Start Guide Package Contents NSM2/NSM3/NSM365/NSM5 NanoStation M 2/M3/M365/M5 Zip Tie PoE (24V, 0.5A) with Mounting Bracket Power Cord locoM2/locoM5 NanoStationloco M 2/M5 Zip Tie PoE (24V, 0.5A) with Mounting Bracket https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
-
Page 2: Installation Requirements
Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit ui.com/toughcable Surge protection should be used for all outdoor installations. -
Page 3: Hardware Overview
NanoStationM/locoM Series Quick Start Guide Hardware Overview NSM2/NSM3/NSM365/NSM5/locoM2/locoM5 https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]... - Page 4 NanoStationM/locoM Series Quick Start Guide https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
- Page 5 NanoStationM/locoM Series Quick Start Guide Power LED The LED will light green when the device is connected to a power source. LAN1 LED The LED will light steady green when an active Ethernet connection is made to the Main/LAN port and flash when there is activity. LAN2 LED (NanoStation M2/M3/M5 only) The LED will light steady green when an active Ethernet connection is made to the Secondary port and flash when there is activity.
- Page 6 NanoStationM/locoM Series Quick Start Guide Note: To use PoE passthrough on the Secondary port, a 24V, 1A PoE adapter is required. Main/LAN* Port This 10/100 Ethernet port is used to connect the power and should be connected to the LAN and DHCP server. Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the device is powered on.
- Page 7 NanoStationM/locoM Series Quick Start Guide Power LED The LED will light green when the device is connected to a power source. LAN1 LED The LED will light steady green when an active Ethernet connection is made to the Main/LAN port and flash when there is activity. Signal LEDs In airOS®, you can modify the threshold values for the wireless signal strength LEDs on the Advanced tab under Signal LED Thresholds.
-
Page 8: Installation
NanoStationM/locoM Series Quick Start Guide Installation https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]... - Page 9 NanoStationM/locoM Series Quick Start Guide https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
- Page 10 NanoStationM/locoM Series Quick Start Guide https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
- Page 11 NanoStationM/locoM Series Quick Start Guide https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
-
Page 12: Connecting Power
NanoStationM/locoM Series Quick Start Guide Connecting Power WARNING: The switch port must comply with the power specifications listed in this Quick Start Guide. https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]... - Page 13 NanoStationM/locoM Series Quick Start Guide Optional Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Make sure that your host system is connected via Ethernet to the device. https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
-
Page 14: Installer Compliance Responsibility
The airOS Configuration Interface will appear, allowing you to customize your settings as needed. For details, refer to the User Guide available at ui.com/download/airmax You can also manage your device using the Ubiquiti® Network Management System. Setup using the UNMS™ app requires the U-Installer, sold separately. Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer’s responsibility to... -
Page 15: Specifications
NanoStationM/locoM Series Quick Start Guide The Antenna Gain and Output Power fields are provided to the professional installer to assist in meeting regulatory requirements. Specifications NanoStationM2/M3/M365/M5 Dimensions 294 x 30 x 80 mm (11.57 x 1.18 x 3.15") Weight NSM2/NSM5 0.4 kg (14.11 oz) NSM3/NSM365 0.5 kg (17.64 oz) - Page 16 NanoStationM/locoM Series Quick Start Guide Operating Humidity 5 to 95% Noncondensing NSM2/NSM3/NSM365 Operating Frequency (MHz) NSM2 2412 - 2462 NSM3 3400 - 3700 NSM365 3650 - 3675 NSM5 Operating Frequency (MHz) Worldwide 5150 - 5875 5150 - 5350, 5470 - 5725, 5725 - 5875 U-NII-1 5150 - 5250 U-NII-2A...
-
Page 17: Safety Notices
NanoStationM/locoM Series Quick Start Guide locoM2 Operating Frequency (MHz) Worldwide 2412 - 2462 locoM5 Operating Frequency (MHz) Worldwide 5150 - 5875 5150 - 5350, 5470 - 5725, 5725 - 5875 U-NII-1 5150 - 5250 U-NII-2A 5250 - 5350 U-NII-2C 5470 - 5725 U-NII-3 5725 - 5850 5470 - 5600, 5650 - 5725, 5725 - 5850... -
Page 18: Limited Warranty
NanoStationM/locoM Series Quick Start Guide d. Protective earthing is provided by Listed AC adapter. Building installation shall provide appropriate short-circuit backup protection. e. Protective bonding must be installed in accordance with local national wiring rules and regulations. Limited Warranty ui.com/support/warranty The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where applicable, specify arbitration instead of jury trials or class actions. -
Page 19: Australia And New Zealand
NanoStationM/locoM Series Quick Start Guide 1. l’appareil ne doit pas produire de brouillage; 2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Le présent émetteur radio a été approuvé par ISDE Canada. Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à... -
Page 20: Weee Compliance Statement
NanoStationM/locoM Series Quick Start Guide Country List BFWA (Broadband Fixed Wireless Access) members noted in blue Note: This device meets Max. TX power limit per ETSI regulations. The following apply to products that operate in the 5 GHz frequency range: Note: This device is restricted to indoor use only when operating in the 5150 - 5350 MHz frequency range within all member states. - Page 21 NanoStationM/locoM Series Quick Start Guide © 2020 Ubiquiti Inc. All rights reserved. https://dl.ubnt.com/qsg/NanoStationM_NanoStationlocoM/NanoStationM_NanoStationlocoM_EN.html[1/27/2020 3:06:49 PM]...
