TorcUP RAPTOR RP Series Repair Instructions

2nd stage raptor replacement
Hide thumbs

Advertisement

Quick Links

Download this manual
Repair Instructions
nd
2
Stage Raptor Replacement

Advertisement

loading
Need help?

Need help?

Do you have a question about the RAPTOR RP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TorcUP RAPTOR RP Series

Summary of Contents for TorcUP RAPTOR RP Series

  • Page 1 Repair Instructions Stage Raptor Replacement...
  • Page 2 Tools required: 3/16 inch allen wrench, pliers & bin for balls...
  • Page 3 Remove ball plug with allen wrench...
  • Page 4 Showing plug removed...
  • Page 5 Place Raptor over bin so balls will drop into bin...
  • Page 6 Write here Rotate annulus alternately counter clockwise allowing balls to drop out...
  • Page 7 Write here Showing a ball dropping out • G:\Raptor_BreakApart\expor\Raptor_Asse mble (10).jpg...
  • Page 8 Write here Continue turning until all balls are out and annulus comes from motor...
  • Page 9 Write here Pull apart gearbox from motor and check to ensure gears are in gear housing as shown...
  • Page 10 Write here Use socket to position gearbox vertically for stability...
  • Page 11 Write here Stable gearbox positioned...
  • Page 12 Write here Use pliers to remove 1 stage gears, keep components on a clean surface...
  • Page 13 Write here Remove 2 gear...
  • Page 14 Write here All gears removed...
  • Page 15 Write here Remove 1 stage carrier, keep components on a clean surface...
  • Page 16 Write here Remove all three 2 stage gears...
  • Page 17 Write here Remove 2 stage carrier...
  • Page 18 Write here Old 2 stage carrier on right, new carrier shown on left...
  • Page 19 Write here Lubricate new 2 stage carrier with Mobil synthetic grease...
  • Page 20 Write here Lubricate liberally as shown...
  • Page 21 Lubricate pins on carrier...
  • Page 22 Install new 2 stage carrier...
  • Page 23 Firmly press down on carrier to ensure proper fit. Gear box should rotate freely on socket...
  • Page 24 Reinstall gears onto on 2 stage...
  • Page 25 Reinstall gear...
  • Page 26 Reinstall gear...
  • Page 27 Showing completed 2 stage assembly...
  • Page 28 Install 1 stage carrier...
  • Page 29 Ensure 1 stage carrier is completely installed...
  • Page 30 Install 1 stage gears...
  • Page 31 Install 1 stage gears...
  • Page 32 Install 1 stage gears...
  • Page 33 Align motor and gear box...
  • Page 34 Showing properly aligned motor and gearbox...
  • Page 35 Turn sideways to expose hole for balls...
  • Page 36 Install 1 ball making sure ball drops completely into baring race...
  • Page 37 Install 1 ball making sure ball drops completely into baring race. May require pulling gear box slightly away of motor to drop the balls in.
  • Page 38 Optional ball bearing assembly tool shown here but not required...
  • Page 39 After installing all balls (number of approx. balls is 35) Gearbox should rotate freely of motor...
  • Page 40 Reinstall ball plug using an allen wrench...
  • Page 41 Completed 2 stage replacement...
  • Page 42 Repair Instructions Stage Raptor Replacement TorcUP Inc Headquarters Industrial Bolting Tools 1025 Conroy Place Easton, PA 18040 USA www.torcup.com 1-888-TorcUP-1 +1-610-250-5800 info@torcup.com...
