ADM from the CONFIGURATION Submenu

Table 5-6: ADM for Low/Medium capacity radios

ADM
Submenu
M12-1/5 T2
ADD/DRP
M12-1/5
DROP & CONT

3xDS3/4xDS3 Terminal

If you selected a T2 ADM for one of the channels, you must configure each of
the M12 Units listed below.
• M12-1 T2 ADD/DRP
• M12-2 T2 ADD/DRP
• M12-3 T2 ADD/DRP
• M12-4 T2 ADD/DRP

Table 5-7: ADM for high capacity radios

ADM
Submenu
M12-1 T2
ADD/DRP
Harris Corporation
Selection Explanation
None Do not drop any T2 signals into these M12 Units
T2-1... 7 T2 to drop into M12.
Drop A Drop T2 on Side A only.
Drop B Drop T2 on Side B only.
Drop&Cont Drop T2 on both A and B sides.
Selection Explanation
None Do not drop any T2 signals into these M12 Units
T2-1... 7 T2 to drop into M12.
5-9
Constellation™
