Replacing a Tape Drive with a Filler Plate

Figure 3 Tape Drive Filler Plate
Replacing a Tape Drive with a Filler Plate
The filler plate is half-height in size. If you remove a full-height tape drive, you
must install two filler plates to cover the opening.
1 The tape drive filler plate has no "top" or "bottom" orientation – it can go in
either way (see Figure 3
2 Slide the filler plate into the slot, and tighten the thumbscrews.
Tape Drive Filler
Plate
Quantum Scalar i40 and Scalar i80: Tape Drive Replacement
on page 7).
Captive thumbscrews
