1.10.b Access the bottom of the cell, compress the foam plug with your
fingers, and carefully pull it out.
1.10.c After removing the foam plug, open the nozzle throat by turning the
white width knob counterclockwise to adjust the setting to E.0.
1.10.d Dispose of the foam plug according to pharmacy policy.
Note
1.11

Remove the baffle cover from each side of the cell:

1.11.a Grasp the round tab at the top of the baffle cover; then pull the tab
toward the opposite end of the baffle cover to remove it from the side
of the cell.
Step 1.11.a
1.11.b Repeat step 1.11.a to remove the baffle cover on the other side of the
cell.
©2015 Parata Systems, LLC
120-0465 Rev 03
You will replace the foam plug you removed here with a new one
later in the procedure. A new foam plug is included in the kit.
