Recommended cables:

3-in-1 keyboard, video and mouse combination cable - For convenience,
neatness and high video quality we recommend the Adder brand 3-in-1 combination
cables. These cables are constructed with tri-coax video links to ensure that high
video quality is maintained. They also support DDC signalling and are colour coded
in PC99 specification colours for your convenience. These match the colours used
on the back of your AdderView GEM and most modern PCs. These cables are
available in various different lengths to suit your requirements. They may be
purchased with or without the adapters for AT keyboards and RS232 serial mice.
Please quote the following part codes when ordering from your supplier.
Part Code
VKVM-2M
VKVM-2M-AT
VKVM-5M
VKVM-5M-AT
VKVM-10M
VKVM-10M-AT
* The optional power adapter may be required (see section 2.4).
A3. Options port pin assignments
The 15 way D connector located on the back of the AdderView GEM (labelled
OPTIONS / FLASH) provides connections for the remote control module and allows
an external RS232 device to control the AdderView GEM. See section 3.6 for more
details.
Pin 9 = GND
Pin 10 = TXD
Pin 11 = RXD
Other pins to be left unconnected
AdderView GEM
Description
3-in-1 Adder cable, 2 metres long
3-in-1 Adder cable, 2 metres long with AT and serial adapters
3-in-1 Adder cable, 5 metres long
3-in-1 Adder cable, 5 metres long with AT and serial adapters
3-in-1 Adder cable, 10 metres long *
3-in-1 Adder cable, 10 metres long with AT and serial adapters *
Installation and Use Page 36
