- Page 1 Operating instruction Translation of the original Deaeration ball valve Type: 5098 DN 15 Connection: Liner / nut Thread P D F • a k • 0 4 / 0 2 / 2 0 2 0 ENGLISH...
- Page 2 . k i e s e l m a n n . d e • i n f o @ k i e s e l m a n n . d e Copyright: © KIESELMANN FLUID PROCESS GROUP...
-
Page 3: Table Of Contents
KIESELMANN GmbH Table of contents T a b l e o f c o n t e n t s 1 General informations .............................. 4 Informations for your safety ............................... 4 Marking of security instructions............................ 4 General designated use .............................. 4 Personnel ..................................... 4 Modifications, spare parts, accessories .......................... 5 General instructions ................................ 5... -
Page 4: General Informations
1 G e n e r a l i n f o r m a t i o n s 1.1 Informations for your safety We are pleased that you have decided for a high-class KIESELMANN GmbH Guth Ventiltechnik GmbH KIESELMANN Anlagenbau GMBH product. With correct application and adequate mainten- ance, our products provide long time and reliable operation. -
Page 5: Modifications, Spare Parts, Accessories
KIESELMANN GmbH | Operating instruction General informations | 1 1.5 Modifications, spare parts, accessories Unauthorized modifications, additions or conversions which affect the safety of the fitting are not permitted. Safety devices must not be bypassed, removed or made inactive. Only use original spare parts and accessories recommended by the manufacturer. -
Page 6: Safety Instructions
2 | Safety instructions Operating instruction | KIESELMANN GmbH 2 S a f e t y i n s t r u c t i o n s 2.1 Intended use The valve is used to vent gaseous media from pipe system in plants of the food and drink industry, pharmaceutical and chemical industries as well as in biotechnology. -
Page 7: Delivery, Transport And Storage
KIESELMANN GmbH | Operating instruction Delivery, transport and storage | 3 3 D e l i v e r y , t r a n s p o r t a n d s t o r a g e 3.1 Delivery... -
Page 8: Specification
4 | Specification Operating instruction | KIESELMANN GmbH 4 S p e c i f i c a t i o n 4.1 Valve types 5098 015 000-xxx 5098 015 070-xxx Ra 1/2‘‘; EPDM Ra 1/2‘‘; EPDM with block pin... -
Page 9: Function And Operation
KIESELMANN GmbH | Operating instruction Function and operation | 5 5 F u n c t i o n a n d o p e r a t i o n 5.1 Description of function The valve is used to vent gaseous media from pipe system. -
Page 10: Service
5 | Function and operation Operating instruction | KIESELMANN GmbH 5.2.2 Service RECOMMENDATION Replacement of seals To achieve optimal maintenance cycles, the following points must be observed! – When replacement of seals, all product-contacting seals should be replaced. – Only original spare parts may be installed. -
Page 11: Technical Data | 6
(in product contact) 1.4301 / AISI 304 Surface: Ra ≤ 0,8µm e-polished Sealing material: EPDM Deareation valve 5098 015 000-xxx Ø - seat: 15 mm Opening pressure: - Closing pressure: 43 mbar(g) System pressure [mbar] Deaeration valve 5098 015 070-xxx Ø... -
Page 12: Disassembly And Assembly
7 | Disassembly and assembly Operating instruction | KIESELMANN GmbH 7 D i s a s s e m b l y a n d a s s e m b l y 7.1 Disassembly Mounting tools Combination wrench-Set SW 8 - SW 24... -
Page 13: Drawings And Dimensions | 8
KIESELMANN GmbH | Operating instruction Drawings and dimensions | 8 8 D r a w i n g s a n d d i m e n s i o n s 8.1 Drawings Pos. Designation Material Item number Housing 1.4404 / AISI 316L...
