10
リアアッパーデッキ
Rear Upper Deck
1-S13008H
3x8mm
1-S33018H
3x18mm
LA358
11
スリッパークラッチ
Slipper Clutch
LA267HD
3
LA266
2
LA207
4mm
BRG014TS
10x15x4mm
LA267HD
LA267HD
1-S53003
3x3mm
LA358
LA358
1
97018-098
2x9.8mm
UM516
LA268
LA266
1-N4056FN-B
1-N4056FN-R
1-S13006H
3x6mm
3
2
1
1-S33008H
3x8mm(F/H)
BRG014TS
10x15x4mm
LA268
UM516
LA206-78
10
3 x 8mm
サラヘックスビス
F/H Hex Screw
2
3 x 6mm
ボタンヘックスビス
Button Hex Screw
4
3 x 8mm
ボタンヘックスビス
Button Hex Screw
2
3 x 18mm サラヘックスビス
F/H Hex Screw
1
本締めする。
Tighten.
11
4mm
フランジ付ナイロンナット
Flanged Nylon Nut
1
10 x 15 x 4mm
ベアリング
Ball Bearing
2
3 x 3mm
セットビス
Set Screw
2 x 9.8mm
ピン
Pin
1
1
バリを取る。
Remove flashing.
凸と凹を合わせる。
挟み込まないように注意する。
Align the
&
grooves.
Prevent them from becoming
sandwiched.
モリブデングリス
Molybdenum Grease
約13.7~14mm
approx. 13.7~14mm
走行時、再度調整をする。
When running, re-adjust.
5
1
