Console Box Remotes
CB-xH Manual
U093.3.0
©2020 Cervis, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmaRT CB-xH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cervis SmaRT CB-xH

Summary of Contents for Cervis SmaRT CB-xH

  • Page 1 ™ Console Box Remotes CB-xH Manual U093.3.0 ©2020 Cervis, Inc.
  • Page 2 SmaRT Console Box Remote This document is the property of Cervis, Inc. and cannot be copied, modified, e-mailed, or reproduced without the express prior written consent of Cervis, Inc. Cervis, Inc. reserves the right to change this manual or edit, delete, or modify any information without prior notification.

  • Page 3: Table Of Contents

    List of Tables ..........................ii Cervis, Inc. Safety Precautions ....................1 1.0 SmaRT Console Box CB-xH Remote Introduction ............2 1.1 SmaRT CB-xH Custom Options ..................3 2.0 CB-xH Console Box Remote ....................4 2.1 CB-xH Diagnostic/Status LEDs ..................4 2.2 CB-xH Battery Installation and Replacement ..............
  • Page 4 SmaRT Console Box Remote List of Figures Figure 1. SmaRT CB-xH Wireless Remote Examples ..............2 Figure 2. CB-xH07LV Console Box ....................4 Figure 3. SmaRT Console Box Battery Installation ..............5 Figure 4. Associate Console Box with Base Unit ..............10 Figure 5. Dissociate Console Box from Base Unit ..............11 Figure 6.

  • Page 5: Cervis, Inc. Safety Precautions

    The first number in the system or device name indicates the operating frequency. For instance, a SmaRT CB-xH (console box) handheld remote in this document may either be CB-2H12LV or CB-9H12JS (or some variation of levers [LV] and joysticks [JS]), where “2”...

  • Page 6: Smart Console Box Cb-Xh Remote Introduction

    CB remote’s ergonomic layout offers comfortable SmaRT system operation. The SmaRT CB-xH also offers a variety of joystick and switch options— several of which are illustrated in Figure 1—that are factory configured to order. The controllers provide a robust link with SmaRT base units in congested radio environments, allowing seamless association without the need to open the enclosures to establish a link.

  • Page 7: Smart Cb-Xh Custom Options

    Umbilical cable option available for backup or network control area network (CAN) control Branding/Labeling Option Cervis, Inc. offers in-house design of attractive custom labels for engineered system CBs, designed in partnership with the customers. Custom labels—made of durable Lexan™ polycarbonate—can include client logos, specific function text, and specific foreground and background colors.

  • Page 8: Cb-Xh Console Box Remote

    SmaRT Console Box Remote 2.0 CB-xH Console Box Remote Figure 2. CB-xH07LV Console Box 2.1 CB-xH Diagnostic/Status LEDs SmaRT CBs have up to eight diagnostic/status LEDs, the first four of which are standard. Table 1. CB-xH Remote LEDs Name Color Function Transmit Green...

  • Page 9: Cb-Xh Battery Installation And Replacement

    Note: Change batteries soon after the first low-battery warning to ensure continued reliable operation. Cervis, Inc. recommends having fresh spare batteries on hand at all times that the system is in use. The console box remote senses when the voltage is at the low power threshold—approximately 2.1 V—at which time, the Amber battery (BATT) LED periodically...

  • Page 10: Neck/Shoulder Harness

    SmaRT Console Box Remote 2.3 Neck/Shoulder Harness The 1¾" wide neck/shoulder harness lets you conveniently and comfortably strap the CB-xH around your neck or shoulder for easy access and operation. Adjustable to lengths up to 60 inches (~1.5 m), the harness conforms to most body lengths; and its rugged, heavy-duty construction and quick-release fasteners keep a single CB-xH securely against your body.

  • Page 11: Attaching The Harness To The Cb-Xh

    To attach the harness to your CB-xH, locate either the two T-shaped harness clips on the front of your CB—one is on the left side; the other is on the right—or the orange bar across the top of ©2020 Cervis, Inc.
  • Page 12 SmaRT Console Box Remote Thread the high visibility orange straps through the harness mounts or bar—snap side up—past the first two (female) snaps. Fold the strap over onto itself, and fasten the female snaps to their male counterparts. ✓ Note: You’ll know the snaps are secured when you hear a clicking sound. U093.3.0...

  • Page 13: Turn Cb-Xh Remote On

    2.5 Turn CB-xH Remote Off Shut down the console box remote using any of the following methods: • Push the Stop switch down for immediate stop. • Flip the ON/OFF switch (S12) DOWN and hold it until the LEDs extinguish. ©2020 Cervis, Inc.

  • Page 14: Associate Console Box With System Base Unit

    SmaRT system base unit receiver before the system can be used. Systems are associated at Cervis, Inc. before leaving the factory; but there may be times when it is necessary to Associate while in the field. The following steps describe the Associate process.

  • Page 15: Dissociate Console Box From System Base Unit

    (S13 and S12) when they go out. Only the console box TX LED is active and none of the base unit LEDs are active, indicating that the communication link is broken. Step 3 Figure 5. Dissociate Console Box from Base Unit ©2020 Cervis, Inc.

  • Page 16: Proportional Output Lever And Joystick Adjustments

    Keep in mind at all times that you are going to control a moving piece of machinery. You must strictly adhere to the safety instructions described in this manual’s Cervis, Inc. Safety Precautions. • Before performing dynamic Min and Max adjustments, make sure the area around the controlled machine is safe to operate.

  • Page 17: Minimum Adjustment

    2. LED 7 goes out and LED 8 lights solid after storing, indicating a return to Select Mode (minimum). Return to Section 2.8.2 to set minimum lever activation.  Note Flipping the Associate switch (S13) DOWN and the Adjust switch (S14) UP toggles between MIN and MAX while in Adjust Mode. ©2020 Cervis, Inc.

  • Page 18: Enter Adjust Mode For Enlarged Base Unit (Ebu) Pwm Outputs

    SmaRT Console Box Remote 2.8.4 Enter Adjust Mode for Enlarged Base Unit (EBU) PWM Outputs After S14, About 4-seconds S13 release S14 S13 S12 Figure 7. Enter Lever or Joystick Adjust Mode (EBU) 1. Release the Stop switch (twist-up or pull-up), and flip the ON/OFF switch (S12) 2.

  • Page 19: Exit Adjust Mode

    Releasing switch and waiting approximately ten seconds for the handheld (when in Select Mode only) to timeout • Pressing the console box Stop switch • Pressing the console box ON/OFF switch (S12) DOWN for three seconds, which powers down the console box. ©2020 Cervis, Inc.

  • Page 20: Umbilical Connection (Option)

    CAN communications. When the CAN option is active, the console box radio is disabled, and all commands are issued to the base unit through the umbilical cable. Cervis, Inc. offers an array of umbilical kits that simplify connecting a SmaRT console box. Figure 8 illustrates an example of a C4-20 Umbilical Kit that may be used in a SmaRT console box system.

  • Page 21: Cb-Xh Remote Console Box Specifications

    SmaRT Console Box Remote 4.0 CB-xH Remote Console Box Specifications Table 3. CB-xH Remote Console Box Specifications SmaRT CB-xH Console Box Specifications Two “C” Cell Batteries Power +1.9 to +3.2 VDC Radio Frequency 906–924 MHz; 2405–2480 MHz License License-Free Modulation...

  • Page 22: Appendix A: Exposure To Radio Frequency Energy

    SmaRT Console Box Remote Appendix A: Exposure to Radio Frequency Energy SmaRT handheld remote units contain radio transceivers. When active, a handheld remote sends out radio frequency (RF) energy through its internal antenna. The SmaRT handheld remote complies with limits set by the United States Federal Communications Commission (FCC) for operating distance from human tissue.

  • Page 23: Appendix C: Agency Identification Label Location

    SmaRT Console Box Remote Appendix C: Agency Identification Label Location  Note: The Agency ID label for all console boxes can be found in the position shown. Agency ID Label Figure 9. Agency Identification Label Locations ©2020 Cervis, Inc.

  • Page 24: Appendix D: Cb-Xh Product Family Listing

    SmaRT Console Box Remote Appendix D: CB-xH Product Family Listing Table 4. CB-xH Common Features Two Type “C” Cell Batteries Power: Dedicated Stop Switch: Oversized, Spring-Loaded Two-Position (Twist-Up) or static Two-position (Pull-Up) Activation: Twist-Up: Twist the Stop Button up, then flip switch S12 up Pull-Up: Pull the Stop Button up, then flip switch S12 up Discrete Inputs Type: Momentary or Maintained Two- or Three-Position Toggle...
  • Page 25 SmaRT Console Box Remote ™ www.cervisinc.com Visit our Web site at: ©2020 Cervis, Inc. All rights reserved. Content is subject to change without notice. ©2020 Cervis, Inc.
