7
CC2530EM
32 kHz Crystal
CC2530F256
EM Connector
P1
(Bottom side)
The CC2530EM is a complete RF module based on one of the recommended reference designs for
the CC2530 radio. The module is equipped with a 32 MHz crystal, a 32.768 kHz crystal, external
passive components for the balun and antenna match filter, an SMA connector for the antenna or any
other RF instrument connection and general IO headers/connectors.
The table below shows the pin-out from the CC2530 to the two connectors on the backside of the
evaluation module.
CC2530
P1
Signal
GND
1
P0.4
3
P0.1
5
P0.2
7
P0.3
9
P0.0
11
P1.1
13
P0.6
15
P0.7
17
GND
19
The part number of the EM connector is SFM-110-02-SM-D-A-K-TR from Samtec. It mates with the
TFM-110-02-SM-D-A-K-TR, also from Samtec.
Please refer to the reference design on the web [1] for further details.
Figure 6 - CC2530 Evaluation Module
CC2530
P1
Signal
2
-
4
P1.3
6
P1.0
8
-
10
P2.1
12
P2.2
14
P1.4
16
P1.5
18
P1.6
20
P1.7
Table 1 - CC2530EM pin-out
CC2530
Signal
-
-
-
VDD
VDD
-
-
RESET
P1.2
P2.0
14/28
swru209b
SMA antenna
connector
32MHz Crystal
EM Connector
P2
(Bottom side)
CC2530
P2
P2
Signal
1
2
-
3
4
-
5
6
-
7
8
-
9
10
-
11
12
-
13
14
-
15
16
-
17
18
P0.5
19
20
-
