Figure 6 - Panel Connection Information
MANUFACTURER
Honeywell
Orisec
Pyronix
Texecom
For Risco, Eaton and UTC, please purchase the relevant cable from the CSL Installer shop. For other connections
or further instructions on Control Panel programming please review the Panel Guides on the Installer Zone of our
website: www.csl-group.com/uk/installer-zone-panel-guides
Figure 7 - Serial Cable (RS232/485/TTL)
STEP 4. TESTING
Please also ensure that you put your device on test with the ARC and perform a full range of test signals
from your control equipment. DualCom Pro paths can be tested using the following method:
• Tap button A until S is shown
• Tap button C to indiciate Path Test
• The display will read out PATH TEST and return to Menu S for 30 seconds before returning to
signal strength
Once you have successfully tested your device, make sure that you check with your ARC to see that
they are receiving signals. This can be achieved by calling your ARC or using their web based secure
platform.
IF YOU HAVE PURCHASED A DUAL PATH DEVICE, YOU MUST ENSURE BOTH PATHS ARE CONNECTED
PANEL CONNECTION
Galaxy
All
Euro/Enforcer
Premier/Elite
BEFORE LEAVING SITE.
CABLE/PLUG ON
RS485
(cable provided)
TTL
(cable
RS232
(cable provided)
TTL
(cable provided)
9
SUPPLIED
CABLES
Green -
4 Pin
Blue -
Red -
Green -
4 Pin
Blue -
provided)
Red -
Green -
6 Pin
Blue -
Red -
Green -
5 Pin
Blue -
Red -
6 Pin - Pyronix
5 Pin - Texecom
4 Pin - Honeywell /
Orisec
RTN
RS485-B
RS485-A
RTN
TTL-T
TTL-R
RTN
RS232-R
RS232-T
RTN
TTL-R
TTL-T
